• Model NO.：Bearing Steel GCR15 Needle Roller Pin
• Sample：Free
• Small Order：Accepted
• Transport Package：Dry, Light Oil, Plastic Bag, Box and Pallet
• Specification：ISO, SGS
• Trademark：OEM, Fuqin
• Origin：China
• HS Code：84829100
• Production Capacity：500000 PCS, Month

Basic Info.

Model NO. Bearing Steel GCR15 Needle Roller Pin Sample Free Small Order Accepted Transport Package Dry, Light Oil, Plastic Bag, Box and Pallet Specification ISO, SGS Trademark OEM, Fuqin Origin China HS Code 84829100 Production Capacity 500000 PCS/ Month

Product Description

Bearing Steel Gcr15 Needle Roller Pin


φ 1.98× 16.25	φ 3.5× 5	φ 5.2× 11	φ 9× 9
φ 1.95× 10.5	φ 3.5× 9.8	φ 5.3× 11	φ 9× 14
φ 1.5× 5.8	φ 3.5× 13.8	φ 5.3× 15	φ 10.2× 11.5
φ 1.5× 4.8	φ 3.5× 10.8	φ 5× 13	φ 10× 10
φ 1.548× 12.7	φ 3.19× 13.8	φ 5× 10	φ 10.15× 10
φ 1.588× 10	φ 3× 12.5	φ 6.5× 6.5	φ 10.2× 10.4
φ 1.5× 7.8	φ 3× 17.8	φ 6× 10	φ 10.2× 9.5
φ 1.81× 13.2	φ 3.1× 3.4	φ 6× 8	φ 10× 14
φ 2.5× 8.0	φ 3× 9.8	φ 6× 12	φ 10× 11
φ 2.5× 10.8	φ 3× 9.5	φ 6.5× 8	φ 10× 24
φ 2.42× 11.8	φ 3× 23.8	φ 6.5× 25	φ 10× 20
φ 2× 13.8	φ 3× 21.8	φ 6× 6.5	φ 10× 13.8
φ 2× 6.8	φ 3× 14.8	φ 6.974× 9.04	φ 11× 11
φ 2× 5.8	φ 3.3× 10	φ 6× 14	φ 11× 16
φ 2.25× 6.8	φ 3.5× 12.8	φ 6.35× 20.8	φ 11× 15
φ 2.546× 15.3	φ 3.446× 11.43	φ 6.5× 9	φ 12× 12
φ 2.9× 9.8	φ 3.96× 8.24	φ 6.04× 12	φ 12× 14
φ 2.55× 10.8	φ 4× 6.8	φ 6× 16	φ 12× 18
φ 2.565× 10.3	φ 4× 14.8	φ 6.35× 12.4	φ 13× 14
φ 2.387× 12	φ 4.76× 11.8	φ 6× 6	φ 14× 14
φ 2.5× 5	φ 4× 8	φ 6.35× 22.23	φ 15× 15
φ 2× 9.8	φ 4.5× 15.5	φ 7.5× 9	φ 15× 16
φ 2× 4.8	φ 4× 16	φ 7.5× 7.5	φ 15× 20
φ 2.5× 9.8	φ 4× 10.8	φ 7× 7	φ 18× 18
φ 2.02× 10.3	φ 4× 5	φ 7.5× 13	φ 19× 19
φ 2.5× 11.8	φ 4× 23.8	φ 7.5× 11	φ 20× 20
φ 2.34× 16.5	φ 4.5× 30	φ 7.5× 6	φ 23× 23
φ 2.387× 16.8	φ 4× 32.8	φ 7.5× 10	φ 12.7× 35.611
φ 2.5× 12.8	φ 4× 4	φ 7× 10	φ 12.7× 44.653
φ 2.8× 6	φ 4× 15.8	φ 7.8× 13	φ 12.7× 56.003
φ 2.9× 11.8	φ 4× 10.8	φ 8× 10	φ 12.7× 71.958
φ 3× 11.8	φ 5× 20	φ 8× 12	φ 22.2× 32
φ 3× 8.8	φ 5× 5	φ 8× 8	φ 22.2× 42
φ 3× 10.8	φ 5× 6	φ 8.02× 11.7	φ 16.32× 54.432
φ 3× 5.75	φ 5× 8	φ 8× 11	φ 16.32× 27.305
φ 3× 5	φ 5.5× 5.5	φ 8.04× 9	φ 34× 34
φ 3× 12.8	φ 5× 17.8	φ 8× 16	φ 34× 54
φ 3.157× 13.8	φ 5.95× 24.2	φ 8× 13	φ 37× 38

Material standard: GCr15 , 100CR6 , SUJ2
Hardness standard: HRC60-64

Grade:G1,G2,G3

Length tolerance:0.2

Diameter tolerance:0.001

TIR:0.006

Ra:0.05 Rz:1.0
End surface shape: round, flat, crowning

Surface finishing: polish-grind, superfinish grinding
