Double Row Tapered/Taper/Conical Roller Bearings for Railway Auto
Wafangdian Jinrui Bearing Manufacturing Co., Ltd.- Rolling Body：Roller Bearings
- The Number of Rows：Multi-column
- Outer Dimension：Small and Medium-Sized (60-115mm)
- Material：Bearing Steel
- Spherical：Aligning Bearings
- Load Direction：Radial Bearing
Base Info
- Model NO.：7307E,30204, 30205, 30206, 30207, 30208
- Separated：Separated
- Materical：Chrome Steel Gcr15
- Precision Rating：P0 P6 P5
- Seals Type：2RS
- Applicatio：Automotive
- Application：Transmission, Motor, Transport
- Brand：OEM Service
- Clearance：C0 C2 C3
- Size：30mm*62mm*17.25mm
- Hardness：59-63HRC
- Noise Level：Z2 Z3
- Feature：Long Life High Speed
- Vibration：V1 V2 V3 V4
- Transport Package：Single Box Packing+Cartons+Pallets
- Specification：40mm-500mm
- Trademark：JRZA or customzied
- Origin：Shandong, China
- HS Code：848220000
- Production Capacity：100000pieces,Year
Description
32200 Series32203 17 40 17.25 16S 14 1 1 27.4 27.5 0.105 32204 20 47 19.25 18 15 1 1 33.1 34.7 0.166 322/22 22 50 19.25 18 15 1 1 0.18 32205 25 52 19.25 18 16 1 1 39.8 44.8 0.187 322/28 28 58 20.25 19 16 1 1 0.243 32206 30 62 21.25 20 17 1 1 50.7 57.9 0.287 322/32 32 65 22.25 21 18 1 1 0.336 32207 35 72 24.25 23 19 1.5 1.5 69.6 82.4 0.445 32208 40 80 24.75 23 19 1.5 1.5 77.7 90.8 0.532 32209 45 85 24.75 23 19 1.5 1.5 84.2 104 0.573 32210 50 90 24.75 23 19 1.5 1.5 85 105 0.626 32211 55 100 26.75 25 21 2 1.5 107 133 0.853 32212 60 110 29.75 28 24 2 1.5 132.8 179.6 1.17 32213 65 120 32.75 31 27 2 1.5 160.9 221.7 1.55 32214 70 125 33.25 31 27 2 1.5 168.5 237.1 1.66 32215 75 130 33.25 31 27 2 1.5 170.3 242.1 1.72 32216 80 140 35.25 33 28 2.5 2 198.1 279 2.1 32217 85 150 38.5 36 30 2.5 2 226.7 324 2.64 32218 90 160 42.5 40 34 2.5 2 269 396 3.41 32219 95 170 45.5 43 37 3 2.5 301 301 4.22 32220 100 180 49 46 39 2 2.5 340 513 5.05 32221 105 190 53 50 43 3 2.5 380 581 6.26 32222 110 200 56 53 46 3.5 2 430 668 7.35 32224 120 215 61.5 58 50 3 2.5 475 764 9 32226 130 230 67.75 64 54 4 3 549 895 11.3
Our packing:
* Industrial pakage+outer carton+pallets
* sigle box+outer carton+pallets
* Tube package+middle box+outer carton+pallets
* According to your requirments
We have been engaged in foreign trade for more than 6 years and are well-known enterprises in Shandong
Province. The fixed assets of the machine are more than 2 million US dollars, and the annual foreign trade
sales volume exceeds 2 million US dollars.
We have extensive cooperation with countries in Asia, Europe, and the Americas. Including Russia, Ukraine,
elarus, Kazakhstan, Uzbekistan, Tajikistan, Spain, Mexico,India, Pakistan, Turkey, Vietnam and other industrial
areas.
SAMPLES
1.Samples quantity: 1-10 pcs are available.
2.Free samples: It depends on the model NO., material and quantity. Some of the bearings samples need client to pay
samples charge and shipping cost.
3.It's better to start your order with Trade Assurance to get full protection for your samples order.
CUSTOMIZED
The customized LOGO or drawing is acceptable for us.
MOQ
1.MOQ: 10 pcs mix different standard bearings.
2.MOQ: 3000 pcs customized your brand bearings.
OEM POLICY
1.We can printing your brand (logo,artwork)on the shield or laser engraving your brand on the shield.
2.We can custom your packaging according to your design
3.All copyright own by clients and we promised don't disclose any info.
SUPORT
Please visit our bearings website, we strongly encourge that you can communicate with us through email,thanks!
Our packing:
* Industrial pakage+outer carton+pallets
* sigle box+outer carton+pallets
* Tube package+middle box+outer carton+pallets
* According to your requirments
We have been engaged in foreign trade for more than 6 years and are well-known enterprises in Shandong
Province. The fixed assets of the machine are more than 2 million US dollars, and the annual foreign trade
sales volume exceeds 2 million US dollars.
We have extensive cooperation with countries in Asia, Europe, and the Americas. Including Russia, Ukraine,
elarus, Kazakhstan, Uzbekistan, Tajikistan, Spain, Mexico,India, Pakistan, Turkey, Vietnam and other industrial
areas.
SAMPLES
1.Samples quantity: 1-10 pcs are available.
2.Free samples: It depends on the model NO., material and quantity. Some of the bearings samples need client to pay
samples charge and shipping cost.
3.It's better to start your order with Trade Assurance to get full protection for your samples order.
CUSTOMIZED
The customized LOGO or drawing is acceptable for us.
MOQ
1.MOQ: 10 pcs mix different standard bearings.
2.MOQ: 3000 pcs customized your brand bearings.
OEM POLICY
1.We can printing your brand (logo,artwork)on the shield or laser engraving your brand on the shield.
2.We can custom your packaging according to your design
3.All copyright own by clients and we promised don't disclose any info.
SUPORT
Please visit our bearings website, we strongly encourge that you can communicate with us through email,thanks!
We have all kinds of bearings, just tell me your item number and quantity,best price will be offered to you soon
The material of the bearings, precision rating, seals type,OEM service,etc, all of them we can make according to your requirement.
