Factory UC309 Bearing Insert Pillow Block Bearings Used for Agricultural/Industry Machinery UCFL309/UCP309/Ucf309/UCT309/Ucfa309 Ball/Roller/Cage Needle Bearing
Tianjin Reet Bearing Co., Ltd.- Aligning：Non-Aligning Bearing
- Separated：Unseparated
- Feature：High Temperature, High Speed
- Rows Number：Single
- Raceway：Deep Groove Raceway
- Material：Bearing Steel
Base Info
- Model NO.：UCFL309
- Bearing Block Model：Fa
- Weight：3.4kg
- Bolt Used：M22
- D：45mm
- a：230mm
- B：57mm
- Bolt：M22
- Transport Package：Individual Box+Pallet
- Specification：45mm
- Trademark：RTB
- Origin：China
- HS Code：8483200000
- Production Capacity：100000 Pieces,Year
Description
Dimension(in)or(mm)Bolt used Bearing Weight No. D(mm) a e i g l s b z Bi n (mm) No. (kg) UCFL305 25 150 113 16 13 29 19 80 39 38 15 M16 UC305 1.1 UCFL306 30 180 134 18 15 32 23 90 44 43 17 M20 UC306 1.5 UCFL307 35 185 141 20 16 36 23 100 49 48 19 M20 UC307 1.8 UCFL308 40 200 158 23 17 40 23 112 56 52 19 M20 UC308 2.4 UCFL309 45 230 177 25 18 44 25 125 60 57 22 M22 UC309 3.4 UCFL310 50 240 187 28 19 48 25 140 67 61 22 M22 UC310 4.3 UCFL311 55 250 198 30 20 52 25 150 71 66 25 M22 UC311 5.2 UCFL312 60 270 212 33 22 56 31 160 78 71 26 M27 UC312 6.3 UCFL313 65 295 240 33 25 58 31 175 78 75 30 M27 UC313 7.9 UCFL314 70 315 250 36 28 61 35 185 81 78 33 M30 UC314 9.3 UCFL315 75 320 260 39 30 66 35 195 89 82 32 M30 UC315 10.6 UCFL316 80 355 285 38 32 68 38 210 90 86 34 M33 UC316 13.5 UCFL317 85 370 300 44 32 74 38 220 100 96 40 M33 UC317 15.2 UCFL318 90 385 315 44 36 76 38 235 100 96 40 M33 UC318 18 UCFL319 95 405 330 59 40 94 41 250 121 103 41 M36 UC319 22.7
New model: UCFLU309
Old model: L 90609
Inner diameter: 45
Outer diameter: 57
Thickness: 125
Type Spherical ball bearing with seat
Detailed description Outer spherical ball bearing with diamond seat top wire:
(UCFLU type)
Remarks S=22, Hmax=230, Amax=44, J=177, A2=2
TIANJIN REET BEARING.CO.,LTD is a professional bearing manufacturer and exporter.
We have a wealth of technical.All producing processes are finished in our manufactory. As an ISO9001:2000 certified manufacturer,we will solve various problems in application and use of our bearings.
Our company is an authorized distributor of FAG, INA, TIMKEN and other world brand bearings.Our company has the right to self-export bearings and launches its own brand RTB.
Our bearing had been exported to more than twenty countries worldwide and are warmly welcomed.
We're looking forward to your order.
FAQ
1.Is the company a production factory or a trading company?
TIANJIN REET BEARING CO.,LTD is a manufacturing enterprise focusing on bearings and integrating research, production and sales.
2.How many the MOQ of your company?
Depending on the size of the bearing, the MOQ is variable, if you are interested, you can contact me for a quote.
3.Does the company accept OEM or customized bearings?
In addition to standard products, we also supply non-standard and modified standard products for special application. Meanwhile, we provide OEM service.
4.Can the company provide free samples?
We can provide samples for free. You only need to provide shipping.
5.What are the company's delivery terms?
We can accept EXW,FOB,CFR,CIF,etc. You can choose the one which is the most convenient cost effective for you.
New model: UCFLU309
Old model: L 90609
Inner diameter: 45
Outer diameter: 57
Thickness: 125
Type Spherical ball bearing with seat
Detailed description Outer spherical ball bearing with diamond seat top wire:
(UCFLU type)
Remarks S=22, Hmax=230, Amax=44, J=177, A2=2
TIANJIN REET BEARING.CO.,LTD is a professional bearing manufacturer and exporter.We have a wealth of technical.All producing processes are finished in our manufactory. As an ISO9001:2000 certified manufacturer,we will solve various problems in application and use of our bearings.
Our company is an authorized distributor of FAG, INA, TIMKEN and other world brand bearings.Our company has the right to self-export bearings and launches its own brand RTB.
Our bearing had been exported to more than twenty countries worldwide and are warmly welcomed.
We're looking forward to your order.
