• Model NO.：F&D bearing 6014
• Cage：Steel
• ABEC：1 ,V2
• Vibration：V2 ,V3,V4
• Customer Logo：YES
• PRINT LOGO：YES
• Certificate：SGS , ISO901, IATF16949
• Transport Package：Tube or Box
• Specification：Subject to right size
• Trademark：F&D, CBB or flate
• Origin：China
• HS Code：8482102000
• Production Capacity：280 Million PCS,Year

 Chemical Composition(%)STEEL NOCSiMnPSCrGCr150.95-1.050.15-0.350.25-0.450.0250.0251.40-1.656.Brand : F&D,CBB or As customers' Brand
7.Packing : Industrial and individual packing
8. Samples Policy : please arrange the sample cost and freight or freight collected. we will reduct this part expense from the total value of our first order.
9.Quality Guarantee : The items can be replaced or refunded beause of quality problem within one year from the date the buyer get the goods .
Packaging More Detail:
1.Plastic tube: 10pcs/tube or 5pcs/tube
2.Single box: plastic bag+single box, OEM supply
3.Carton: Standard export carton or as your need

F&D bearing 6014 for agriculture machine parts

1. Series: 6000, 6200, 6300
2. Model Open: Z, ZZ, RZ, 2RZ, RS, 2RS.
3. Quality accords with the Industry Standards.
4. Types: Single Row DBGG, Double Row DGBB, Stainless DBGG, DBGG with filling slots, Stainless Steel single Row DBGG, Single Row Hybrid DBGG, Single Row DBGG for High Temperature, Polymer Ball Bearings and soon.
5. Typical Applications: Bowling pinsetters, electric motors, elevators, fork lift trucks, paper converting, power tools, printing machinery, pumps, textile machinery, woodworking and so on.


	Bearing Type	Pro-type NO.	I.D. d	O.D. D	Width B	Rated Dynamic Load Cor (KN)	Rated Dynamic Load Cr (KN)	Grease	Oil	Weight
1	6000	100	10	26	8			30000	20000	0.016
2	6002	102	15	32	9	5.60	2.85	23000	27000	0.030
3	6003	103	17	35	10	6.00	3.25	21000	25000	0.039
4	6004	104	20	42	12	9.40	5.05	17000	21000	0.069
5	6005	105	25	47	12	10.1	5.85	15000	18000	0.080
6	6006	106	30	55	13	13.2	8.25	13000	15000	0.116
7	6007	107	35	62	14	15.9	10.3	11000	13000	0.155
8	6008	108	40	68	15	16.7	11.5	10000	121000	0.192
9	6009	109	45	75	16	21.0	15.1	9200	11000	0.245
10	6010	110	50	80	16	21.8	16.6	8400	9900	0.261
11	6011	111	55	90	18	28.3	21.2	7600	8900	0.385
12	6012	112	60	95	18	29.4	23.2	7100	8400	0.410
13	6013	113	65	100	18	30.5	25.2	6600	7800	0.435
14	6014	114	70	110	20	38.1	30.9	6100	7200	0.602
15	6015	115	75	115	20	39.5	33.5	5700	6800	0.638
16	6016	116	80	125	22	47.6	39.8	5300	6300	0.850
17	6017	117	85	130	22	49.5	43.1	5000	5900	0.890
18	6018	118	90	140	24	58.2	49.7	4700	5600	1.61
19	6019	119	95	145	24	60.2	53.9	4400	5200	1.21
20	6020	220	100	150	24	60.4	54.2	4300	5100	1.25
21	6021	221	105	160	26	72.3	65.8	4000	4700	1.59
22	6022	222	110	170	28	82.0	73.0	3800	4500	1.96
23	6024	224	120	180	28	85.0

Deep groove ball bearings have deep, uninterrupted raceway grooves. These raceway
grooves have a close osculation with the balls, enabling the bearings to accomodate
radial and axial loads in both directions.
