• Model NO.：7000C series(15), 7000AC series(25), 7000B(40)
• Structure：Angular Contact, Ball Beairng
• Precision Rating：P0 P6 P5 P4, P0, P6, P5, P4
• Feature：Long Life High Speed Low Noise
• Bore Size：60 mm
• Outside Diameter：85 mm
• Bearing Clearance：C0, C2, C3, C4
• Vibration Grade：V1, V2, V3, V4
• Transport Package：Export Standard Industrial Packing
• Specification：71912C
• Trademark：CVP or OEM
• Origin：China
• HS Code：8482103000
• Production Capacity：100000,Month

Basic Info.

Model NO. 7000C series(15), 7000AC series(25), 7000B(40) Structure Angular Contact, Ball Beairng Precision Rating P0 P6 P5 P4, P0, P6, P5, P4 Feature Long Life High Speed Low Noise Bore Size 60 mm Outside Diameter 85 mm Bearing Clearance C0, C2, C3, C4 Vibration Grade V1, V2, V3, V4 Transport Package Export Standard Industrial Packing Specification 71912C Trademark CVP or OEM Origin China HS Code 8482103000 Production Capacity 100000/Month

Product Description

Bearing Feature:

Angular Contact Ball Bearing is mainly applied on high speed, high precision and little axial load occasions, such as airplane engine main shaft, machine tool main shaft and main shafts of other high speed precision machine. It can also be applied on high frequency motor, steam turbine, oil pump, air compressor and printing machine etc. It is one of the bearings most widely used in machinery industry.



Applications:

Single row angular contact ball bearings: machine tool spindles, high frequency motors, gas turbines, centrifuges, small car front wheel, differential pinion shaft, booster pumps, drilling platforms, food machinery, dividing head, fill welder, low-noise cooling towers, electrical and mechanical equipment, painting equipment, machine slot board, arc welding machine.
Double row angular contact ball bearings: pump, blower, air compressor, various types of transmission, fuel injection pumps, printing machinery, planetary reducer, extraction equipment, cycloid reducer, food packaging machinery, welding machines, electric irons, square box, gravity gun, wire strippers, axle, test analysis equipment, fine chemicals, machinery.



Product Number	Bore Dia (d)	Outer Dia (D)	Width (B)	Dynamic Load Rating (Cr) (kN)	Static Load Rating (Cor) (kN)
7000	10 mm	26mm	8mm	4.65	2.07
7001	12 mm	28 mm	8 mm	5.05	2.46
7002	15 mm	32 mm	9 mm	5.8	3.15
7003	17 mm	35 mm	10 mm	7.15	3.85
7004	20 mm	42mm	12mm	9.7	5.6
7005	25 mm	47mm	12mm	10.7	6.85
7006	30 mm	55mm	13mm	13.9	9.45
7007	35 mm	62mm	14mm	17.5	12.6
7008	40 mm	68mm	15mm	18.8	14.6
7009	45 mm	75mm	16mm	22.3	17.7
7010	50 mm	80mm	16mm	23.7	20.1
7011	55 mm	90mm	18mm	31	26.3
7012	60 mm	95mm	18mm	32	28.1
7013	65 mm	100mm	18mm	33.5	31.5
7014	70 mm	110mm	20mm	42.5	39.5
7015	75 mm	115mm	20mm	43.5	41.5
7016	80 mm	125mm	22mm	53.5	50.5
7017	85 mm	130mm	22mm	54.5	53.5
7018	90 mm	140mm	24mm	65	63.5
7019	95 mm	145mm	24mm	67	67
7020	100 mm	150mm	24mm	68.5	70.5
7021	105 mm	160mm	26mm	80	81.5
7022	110 mm	170mm	28mm	92	93
7024	120 mm	180mm	28mm	93.5	98.5
7026	130 mm	200mm	33mm	117	125
7028	140 mm	210mm	33mm	120	133
7030	150 mm	225mm	35mm	137	154
7032	160 mm	240mm	38mm	155	176
7034	170 mm	260mm	42mm	186	214
7036	180 mm	280mm	46mm	219	266
7038	190 mm	290mm	46mm	224	280
7040	200 mm	310mm	51mm	252	325
