Sk 7mm X 17mm X 5mm 697zz Deep Groove Mini Ball Bearing
Shandong TFN Bearing Industry Co., Ltd.- Contact Angle：0
- Aligning：Non-Aligning Bearing
- Separated：Unseparated
- Rows Number：Single
- Load Direction：Radial Bearing
- Material：Bearing Steel
Base Info
- Model NO.：697ZZ
- Product Name：Sk 7mm X 17mm X 5mm 697zz Deep Groove Mini Ball B
- Size：7mm X 17mm X 5mm
- Application：Machinery
- Feature：Long Life
- Vibration：Zv1, Zv2, Zv3, or as Requested
- Service：OEM Customized Services
- Certificate：ISO9001:2000
- Package：Original Package
- Main Market：America Europe Asia Middle
- Bearing Material：Gcr15,Bearing Steel,Stainless Steel
- Transport Package：Single Box Packaging,OEM
- Specification：7mm x 17mm x 5mm
- Trademark：TFN,OEM,SEMRI
- Origin：China
- HS Code：8482102000
- Production Capacity：10000,Month
Description
Quality Control Process 1.Assembly 2.Windage test2.Windage test 3.Cleaning 4.Rotary test 5.Greasing and gland 6.Noise inspection 7.Appearance inspection 8.Rust prevention 9.Product packaging Application low noise machine,automobile,motorcycle,and the general machinery and etc. Mass(Kg) d D B rs min Cr Cor Grease Oil (Approx.) 60 Series 6000 10 26 8 0.3 4.55 1.96 29,000 34,000 0.019 6001 12 28 8 0.3 5.1 2.39 26,000 30,000 0.021 6002 15 32 9 0.3 5.6 2.83 22,000 26,000 0.03 6003 17 35 10 0.3 6.8 3.35 20,000 24,000 0.039 6004 20 42 12 0.6 9.4 5.05 18,000 21,000 0.069 6005 25 47 12 0.6 10.1 5.85 15,000 18,000 0.08 6006 30 55 13 1 13.2 8.3 13,000 15,000 0.116 6007 35 62 14 1 16 10.3 12,000 14,000 0.155 6008 40 68 15 1 16.8 11.5 10,000 12,000 0.19 6009 45 75 16 1 21 15.1 9,200 11,000 0.237 6010 50 80 16 1 21.8 16.6 8,400 9,800 0.261 6011 55 90 18 1.1 28.3 21.2 7,700 9,000 0.388 6012 60 95 18 1.1 29.5 23.2 7,000 8,300 0.414 6013 65 100 18 1.1 30.5 25.2 6,500 7,700 0.421 6014 70 110 20 1.1 38 31 6,100 7,100 0.604 6015 75 115 20 1.1 39.5 33.5 5,700 6,700 0.649 6016 80 125 22 1.1 47.5 40 5,300 6,200 0.854 6017 85 130 22 1.1 49.5 43 5,000 5,900 0.89 6018 90 140 24 1.5 58 49.5 4,700 5,600 1.02 6019 95 145 24 1.5 60.5 54 4,500 5,300 1.08 6020 100 150 24 1.5 60 54 4,200 5,000 1.15 6021 105 160 26 2 72.5 65.5 4,000 4,700 1.59 6022 110 170 28 2 82 73 3,800 4,500 1.96 6024 120 180 28 2 85 79.5 3,500 4,100 2.07 6026 130 200 33 2 106 101 3,200 3,800 3.16 6028 140 210 33 2 110 109 3,000 3,500 3.35 6030 150 225 35 2.1 126 126 2,800 3,200 4.08 6032 160 240 38 2.1 143 144 2,600 3,000 5.05 6034 170 260 42 2.1 168 172 2,400 2,800 6.76 6036 180 280 46 2.1 189 199 2,300 2,700 8.8 6038 190 290 46 2.1 197 215 2,100 2,500 9.18 6040 200 310 51 2.1 218 243 2,000 2,400 11.9 6044 22 340 56 3 235 271 1,700 2,000 19 6044M 220 340 56 3 245 293 1,800 2,200 19.8 6048M 240 360 56 3 255 315 1,700 2,000 20.7 6052M 260 400 65 4 294 373 1,500 1,800 28.8 6056 280 420 65 4 302 408 1,300 1,500 32.1 6060 300 460 74 4 355 482 1,200 1,400 42.8 6064 320 480 82 4 352 487 1,100 1,300 48.4 6068 340 520 82 5 441 661 980 1,200 67.2 6072 360 540 82 5 438 668 920 1,100 68 6080 400 600 90 5 508 824 780 920 87.4 6088 440 650 94 6 526 902 800 1,000 107 6092 460 680 100 6 577 1000 750 950 130 60/500 500 720 100 6 600 1100 570 670 140 60/530 530 780 100 6 680 1300 700 800 186 60/630N1 630 920 128 7.5 750 1620 560 670 294 60/710N1/C3 710 1030 140 7.5 1020 2310 450 560 390 60/800N1/C9 800 1150 155 7.5 1090 2690 380 480 548 60/22 22 44 12 0.6 955 515 17,000 20,000 0.074 60/28 28 52 12 0.6 1270 755 14,000 16,000 0.098 60/32 32 58 13 1 1200 820 12,000 15,000 0.129
FAQ
FAQ
1.Q:Are you a factory or trading company?
A:SEMRI Bearing is specialized in manufacturing and exporting bearings.
SEMRI Bearing have own factory and warehouse.
2.Q:Can I get some samples and do you offer the sample free?
A:Yes, sure, SEMRI Bearing are honored to offer you samples.Can you buy a ticket ?3.Q:What is the payment?
A: 30% T/T In Advance, 70% T/T Against Copy Of B/L
B: 100% L/C At Sight
4.Q:What is the MOQ for bearing?
A: SEMRI Bearing MOQ is 1 pc.
5.Q:What kind of service you can offer?
A:Technology support;Installation guidance;OEM
