Inch Deep Groove Ball Bearing RM-5-2RS 15.872*46.038*15.875mm
Shandong TFN Bearing Industry Co., Ltd.- Contact Angle：0
- Aligning：Non-Aligning Bearing
- Separated：Unseparated
- Rows Number：Single
- Load Direction：Radial Bearing
- Material：Bearing Steel
Base Info
- Model NO.：RM-5-2RS
- Product Name：Inch Deep Groove Ball Bearing RM-5-2RS
- Cage：Gcr15 Chrome Steel
- Seals Type：Zz 2RS Open
- Precision Rating：ABEC-1, ABEC-3, ABEC-5, ABEC-7
- Application：Agricultural Machinery
- Transport Package：Single Box Packaging,OEM
- Specification：8*28*6 mm
- Trademark：TFN,OEM
- Origin：China
- HS Code：8482102000
- Production Capacity：10000,Month
Description
Quality Control Process 1.Assembly 2.Windage test2.Windage test 3.Cleaning 4.Rotary test 5.Greasing and gland 6.Noise inspection 7.Appearance inspection 8.Rust prevention 9.Product packaging Application low noise machine,automobile,motorcycle,and the general machinery and etc. Cr Cor (Approx.) in mm in mm in mm in mm RMS Series RMS4 1/2 12.700 1-5/8 41.275 5/8 15.875 1/16 900 570 21000 0.10 RMS5 5/8 15.875 1-13/16 46.038 5/8 15.875 1/16 1060 630 17000 0.11 RMS6 3/4 19.050 2 50.800 11/16 17.462 1/16 1240 850 16000 0.16 RMS7 7/8 22.225 2-1/4 57.150 11/16 17.462 1/16 1450 930 15000 0.20 RMS8 1 25.400 2-1/2 63.500 3/4 19.050 3/32 1860 1240 12000 0.25 RMS9 1-1/8 28.575 2-13/16 71.438 13/16 20.638 3/32 1810 1230 12000 0.38 RMS10 1-1/4 31.750 3-1/8 79.375 7/8 22.225 3/32 2350 1610 10500 0.51 RMS-2RS Series RMS4-2RS 1/2 12.700 1-5/8 41.275 5/8 15.875 1/16 900 570 17000 0.10 RMS5-2RS 5/8 15.875 1-13/16 46.038 5/8 15.875 1/16 1060 630 14000 0.11 RMS6-2RS 3/4 19.050 2 50.800 11/16 17.462 1/16 1240 850 13000 0.16 RMS7-2RS 7/8 22.225 2-1/4 57.150 11/16 17.462 1/16 1450 930 12000 0.20 RMS8-2RS 1 25.400 2-1/2 63.500 3/4 19.050 3/32 1860 1240 10000 0.25 RMS9-2RS 1-1/8 28.575 2-13/16 71.438 13/16 20.638 3/32 1810 1230 9600 0.38 RMS10-2RS 1-1/4 31.750 3-1/8 79.375 7/8 22.225 3/32 2350 1610 8400 0.51 RMS-ZZ Series RMS4-ZZ 1/2 12.700 1-5/8 41.275 5/8 15.875 1/16 900 570 17000 0.10 RMS5-ZZ 5/8 15.875 1-13/16 46.038 5/8 15.875 1/16 1060 630 14000 0.11 RMS6-ZZ 3/4 19.050 2 50.800 11/16 17.462 1/16 1240 850 13000 0.16 RMS7-ZZ 7/8 22.225 2-1/4 57.150 11/16 17.462 1/16 1450 930 12000 0.20 RMS8-ZZ 1 25.400 2-1/2 63.500 3/4 19.050 3/32 1860 1240 10000 0.25 RMS9-ZZ 1-1/8 28.575 2-13/16 71.438 13/16 20.638 3/32 1810 1230 9600 0.38 RMS10-ZZ 1-1/4 31.750 3-1/8 79.375 7/8 22.225 3/32 2350 1610 8400 0.51 RMS-2RDC3P6QE6 Series RMS4-2RDC3P6QE6 1/2 12.700 1-5/8 41.275 5/8 15.875 1/16 900 570 17000 0.10 RMS5-2RDC3P6QE6 5/8 15.875 1-13/16 46.038 5/8 15.875 1/16 1060 630 14000 0.11 RMS6-2RDC3P6QE6 3/4 19.050 2 50.800 11/16 17.462 1/16 1240 850 13000 0.16 RMS7-2RDC3P6QE6 7/8 22.225 2-1/4 57.150 11/16 17.462 1/16 1450 930 12000 0.20 RMS8-2RDC3P6QE6 1 25.400 2-1/2 63.500 3/4 19.050 3/32 1860 1240 10000 0.25 RMS9-2RDC3P6QE6 1-1/8 28.575 2-13/16 71.438 13/16 20.638 3/32 1810 1230 9600 0.38 RMS10-2RDC3P6QE6 1-1/4 31.750 3-1/8 79.375 7/8 22.225 3/32 2350 1610 8400 0.51 RMS-N Series RMS4-N 1/2 12.700 1-5/8 41.275 5/8 15.875 1/16 900 570 21000 0.10 RMS5-N 5/8 15.875 1-13/16 46.038 5/8 15.875 1/16 1060 630 17000 0.11 RMS6-N 3/4 19.050 2 50.800 11/16 17.462 1/16 1240 850 16000 0.16 RMS7-N 7/8 22.225 2-1/4 57.150 11/16 17.462 1/16 1450 930 15000 0.20 RMS8-N 1 25.400 2-1/2 63.500 3/4 19.050 3/32 1860 1240 12000 0.25 RMS9-N 1-1/8 28.575 2-13/16 71.438 13/16 20.638 3/32 1810 1230 12000 0.38 RMS10-N 1-1/4 31.750 3-1/8 79.375 7/8 22.225 3/32 2350 1610 10500 0.51
deep groove ball bearing packaging
FAQ of deep groove ball bearing
deep groove ball bearing packagingFAQ of deep groove ball bearing
1.Q:Are you a factory or trading company?
A:SEMRI Bearing is specialized in manufacturing and exporting bearings.
SEMRI Bearing have own factory and warehouse.
2.Q:Can I get some samples and do you offer the sample free?
A:Yes, sure, SEMRI Bearing are honored to offer you samples.Can you buy a ticket ?3.Q:What is the payment?
A: 30% T/T In Advance, 70% T/T Against Copy Of B/L
B: 100% L/C At Sight
4.Q:What is the MOQ for bearing?
A: SEMRI Bearing MOQ is 1 pc.
5.Q:What kind of service you can offer?
A:Technology support;Installation guidance;OE
