Spherical Roller Bearing 22336cckw33
Shandong TFN Bearing Industry Co., Ltd.- Rolling Body：Roller Bearings
- The Number of Rows：Double
- Outer Dimension：Large (200-430mm)
- Material：Bearing Steel
- Spherical：Aligning Bearings
- Load Direction：Radial Bearing
Base Info
- Model NO.：22336CCKW33
- Separated：Unseparated
- Product Name：22336cckw33 Spherical Roller Bearing
- Size：180X380X126mm
- Weight：72.6kg
- Basic Dynamic Load Rating：2077kn
- Basic Static Load Rating：2450kn
- Fatigue Load Limit：193kn
- Reference Speed：1300r,Min
- Limiting Speed：1700r,Min
- Calculation Factor：0.35
- Vibration：Zv1, Zv2, Zv3, or as Requested
- Transport Package：Single Box Packaging,OEM
- Specification：180x380x126mm
- Trademark：TFN,OEM
- Origin：China
- HS Code：8482101000
- Production Capacity：10000,Month
Description
Quality Control Process 1.Assembly 2.Windage test2.Windage test 3.Cleaning 4.Rotary test 5.Greasing and gland 6.Noise inspection 7.Appearance inspection 8.Rust prevention 9.Product packaging Application low noise machine,automobile,motorcycle,and the general machinery and etc. Mass(Kg) d D B rs min Cr Cor Grease Oil (Approx.) 223 Series 22308 40 90 33 1.5 121 128 3,800 5,900 0.974 22308K 40 90 33 1.5 121 128 3,800 5,900 0.951 22308KW33C3 40 90 33 1.5 121 128 3,800 5,900 0.951 22308W33C3 40 90 33 1.5 121 128 3,800 5,900 0.974 22309 45 100 36 1.5 148 167 3,400 5,300 1.33 22309K 45 100 36 1.5 148 167 3,400 5,300 1.3 22309KW33C3 45 100 36 1.5 148 167 3,400 5,300 1.3 22309W33C3 45 100 36 1.5 148 167 3,400 5,300 1.33 22310 50 110 40 2 186 212 3,100 4,800 1.79 22310K 50 110 40 2 186 212 3,100 4,800 1.75 22310KW33C3 50 110 40 2 186 212 3,100 4,800 1.75 22310W33C3 50 110 40 2 186 212 3,100 4,800 1.79 22311 55 120 43 2 204 234 2,800 4,400 2.3 22311K 55 120 43 2 204 234 2,800 4,400 2.25 22311KW33C3 55 120 43 2 204 234 2,800 4,400 2.25 22311W33C3 55 120 43 2 204 234 2,800 4,400 2.3 22312 60 130 46 2.1 238 273 2,600 4,000 2.9 22312K 60 130 46 2.1 238 273 2,600 4,000 2.83 22312KW33C3 60 130 46 2.1 238 273 2,600 4,000 2.83 22312W33C3 60 130 46 2.1 238 273 2,600 4,000 2.9 22313 65 140 48 2.1 265 320 2,400 3,700 3.45 22313K 65 140 48 2.1 265 320 2,400 3,700 3.37 22313KW33C3 65 140 48 2.1 265 320 2,400 3,700 3.37 22313W33C3 65 140 48 2.1 265 320 2,400 3,700 3.45 22314 70 150 51 2.1 325 380 2,300 3,500 4.22 22314K 70 150 51 2.1 325 380 2,300 3,500 4.12 22314KW33C3 70 150 51 2.1 325 380 2,300 3,500 4.12 22314W33C3 70 150 51 2.1 325 380 2,300 3,500 4.22 22315 75 160 55 2.1 330 410 2,100 3,200 5.25 22315K 75 160 55 2.1 330 410 2,100 3,200 5.13 22315KW33C3 75 160 55 2.1 330 410 2,100 3,200 5.13 22315W33C3 75 160 55 2.1 330 410 2,100 3,200 5.25 22316 80 170 58 2.1 385 470 2,000 3,000 6.05 22316K 80 170 58 2.1 385 470 2,000 3,000 5.91 22316KW33C3 80 170 58 2.1 385 470 2,000 3,000 5.91 22316W33C3 80 170 58 2.1 385 470 2,000 3,000 6.05 22317 85 180 60 3 415 510 1,900 2,900 7.1 22317K 85 180 60 3 415 510 1,900 2,900 6.94 22317KW33C3 85 180 60 3 415 510 1,900 2,900 6.94 22317W33C3 85 180 60 3 415 510 1,900 2,900 7.1 22318 90 190 64 3 480 590 1,800 2,700 8.35 22318K 90 190 64 3 480 590 1,800 2,700 8.16 22318KW33C3 90 190 64 3 480 590 1,800 2,700 8.16 22318W33C3 90 190 64 3 480 590 1,800 2,700 8.35 22319 95 200 67 3 500 615 1,600 2,500 9.76 22319K 95 200 67 3 500 615 1,600 2,500 9.54 22319KW33C3 95 200 67 3 500 615 1,600 2,500 9.54 22319W33C3 95 200 67 3 500 615 1,600 2,500 9.76 22320 100 215 73 3 605 755 1,600 2,400 12.4 22320K 100 215 73 3 605 755 1,600 2,400 12.1 22320KW33C3 100 215 73 3 605 755 1,600 2,400 12.1 22320W33C3 100 215 73 3 605 755 1,600 2,400 12.4 22322 110 240 80 3 745 930 1,400 2,200 17.1 22322K 110 240 80 3 745 930 1,400 2,200 16.7 22322KW33C3 110 240 80 3 745 930 1,400 2,200 16.7 22322W33C3 110 240 80 3 745 930 1,400 2,200 17.1 22324 120 260 86 3 880 1120 1,300 2,000 21.5 22324K 120 260 86 3 880 1120 1,300 2,000 21 22324KW33C3 120 260 86 3 880 1120 1,300 2,000 21 22324W33C3 120 260 86 3 880 1120 1,300 2,000 21.5 22326 130 280 93 4 1000 1290 1,200 1,800 26.8 22326K 130 280 93 4 1000 1290 1,200 1,800 26.2 22326KW33C3 130 280 93 4 1000 1290 1,200 1,800 26.2 22326W33C3 130 280 93 4 1000 1290 1,200 1,800 26.8 22328 140 300 102 4 1130 1460 1,100 1,700 33.8 22328K 140 300 102 4 1130 1460 1,100 1,700 33 22328KW33C3 140 300 102 4 1130 1460 1,100 1,700 33 22328W33C3 140 300 102 4 1130 1460 1,100 1,700 33.8 22330 150 320 108 4 1270 1750 1,000 1,600 42.7 22330K 150 320 108 4 1270 1750 1,000 1,600 41.8 22330KW33C3 150 320 108 4 1270 1750 1,000 1,600 41.8 22330W33C3 150 320 108 4 1270 1750 1,000 1,600 42.7 22332 160 340 114 4 1410 1990 940 1,500 50.8 22332K 160 340 114 4 1410 1990 940 1,500 49.7 22332KW33C3 160 340 114 4 1410 1990 940 1,500 49.7 22332W33C3 160 340 114 4 1410 1990 940 1,500 50.8 22334 170 360 120 4 1540 2180 880 1,400 59.8 22334K 170 360 120 4 1540 2180 880 1,400 58.5 22334KW33C3 170 360 120 4 1540 2180 880 1,400 58.5 22334W33C3 170 360 120 4 1540 2180 880 1,400 59.8 22336 180 380 126 4 1740 2560 830 1,300 70 22336K 180 380 126 4 1740 2560 830 1,300 68.5 22336KW33C3 180 380 126 4 1740 2560 830 1,300 68.5 22336W33C3 180 380 126 4 1740 2560 830 1,300 70 22338 190 400 132 5 1870 2790 780 1,200 81 22338K 190 400 132 5 1870 2790 780 1,200 79.3 22338KW33C3 190 400 132 5 1870 2790 780 1,200 79.3 22338W33C3 190 400 132 5 1870 2790 780 1,200 81 22340 200 420 138 5 2040 3050 740 1,100 93.2 22340K 200 420 138 5 2040 3050 740 1,100 91.2 22340KW33C3 200 420 138 5 2040 3050 740 1,100 91.2 22340W33C3 200 420 138 5 2040 3050 740 1,100 93.2 22344 220 460 145 5 2350 3500 660 1,000 117 22344K 220 460 145 5 2350 3500 660 1,000 115 22344KW33C3 220 460 145 5 2350 3500 660 1,000 115 22344W33C3 220 460 145 5 2350 3500 660 1,000 117 22348 240 500 155 5 2720 4100 600 930 148 22348K 240 500 155 5 2720 4100 600 930 145 22348KW33C3 240 500 155 5 2720 4100 600 930 145 22348W33C3 240 500 155 5 2720 4100 600 930 148 22352 260 540 165 6 3100 4750 550 850 183 22352K 260 540 165 6 3100 4750 550 850 179 22352KW33C3 260 540 165 6 3100 4750 550 850 179 22352W33C3 260 540 165 6 3100 4750 550 850 183 22356 280 580 175 6 3500 5350 500 780 224 22356K 280 580 175 6 3500 5350 500 780 220 22356KW33C3 280 580 175 6 3500 5350 500 780 220 22356W33C3 280 580 175 6 3500 5350 500 780 224 22360 300 620 185 7.5 3600 5400 470 720 270 22360K 300 620 185 7.5 3600 5400 470 720 265 22360KW33C3 300 620 185 7.5 3600 5400 470 720 265 22360W33C3 300 620 185 7.5 3600 5400 470 720 270 22372 360 750 244 7.5 4180 7500 280 360 494 22380 400 820 243 7.5 5400 9600 340 430 650
spherical roller bearing packaging
FAQ of spherical roller bearing
spherical roller bearing packagingFAQ of spherical roller bearing
1.Q:Are you a factory or trading company?
A:SEMRI Bearing is specialized in manufacturing and exporting bearings.
SEMRI Bearing have own factory and warehouse.
2.Q:Can I get some samples and do you offer the sample free?
A:Yes, sure, SEMRI Bearing are honored to offer you samples.Can you buy a ticket ?3.Q:What is the payment?
A: 30% T/T In Advance, 70% T/T Against Copy Of B/L
B: 100% L/C At Sight
4.Q:What is the MOQ for bearing?
A: SEMRI Bearing MOQ is 1 pc.
5.Q:What kind of service you can offer?
A:Technology support;Installation guidance;OE
