• Model NO.：7007C
• Application：Machinery
• Precision：Po P5
• Feature：Long Life High Speed Low Price
• Certification：SGS ISO9001
• Inner Diameter：3-360mm
• Outer Dimension：8-480mm
• Transport Package：Exported Standard Industrial
• Specification：Customed
• Trademark：CVP or OEM
• Origin：China
• HS Code：8482102000
• Production Capacity：100000,Month

Basic Info.

Model NO. 7007C Application Machinery Precision Po P5 Feature Long Life High Speed Low Price Certification SGS ISO9001 Inner Diameter 3-360mm Outer Dimension 8-480mm Transport Package Exported Standard Industrial Specification Customed Trademark CVP or OEM Origin China HS Code 8482102000 Production Capacity 100000/Month

Product Description

35*62*14 angular contact ball bearings 7007C



Product Number	Bore Dia (d)	Outer Dia (D)	Width (B)	Dynamic Load Rating (Cr) (kN)	Static Load Rating (Cor) (kN)
7000	10 mm	26mm	8mm	4.65	2.07
7001	12 mm	28 mm	8 mm	5.05	2.46
7002	15 mm	32 mm	9 mm	5.8	3.15
7003	17 mm	35 mm	10 mm	7.15	3.85
7004	20 mm	42mm	12mm	9.7	5.6
7005	25 mm	47mm	12mm	10.7	6.85
7006	30 mm	55mm	13mm	13.9	9.45
7007	35 mm	62mm	14mm	17.5	12.6
7008	40 mm	68mm	15mm	18.8	14.6
7009	45 mm	75mm	16mm	22.3	17.7
7010	50 mm	80mm	16mm	23.7	20.1
7011	55 mm	90mm	18mm	31	26.3
7012	60 mm	95mm	18mm	32	28.1
7013	65 mm	100mm	18mm	33.5	31.5
7014	70 mm	110mm	20mm	42.5	39.5
7015	75 mm	115mm	20mm	43.5	41.5
7016	80 mm	125mm	22mm	53.5	50.5
7017	85 mm	130mm	22mm	54.5	53.5
7018	90 mm	140mm	24mm	65	63.5
7019	95 mm	145mm	24mm	67	67
7020	100 mm	150mm	24mm	68.5	70.5
7021	105 mm	160mm	26mm	80	81.5
7022	110 mm	170mm	28mm	92	93
7024	120 mm	180mm	28mm	93.5	98.5
7026	130 mm	200mm	33mm	117	125
7028	140 mm	210mm	33mm	120	133
7030	150 mm	225mm	35mm	137	154
7032	160 mm	240mm	38mm	155	176
7034	170 mm	260mm	42mm	186	214
7036	180 mm	280mm	46mm	219	266
7038	190 mm	290mm	46mm	224	280
7040	200 mm	310mm	51mm	252	325
