Original Import Bearing 22211ek Spherical Roller Bearings
Shandong TFN Bearing Industry Co., Ltd.- Contact Angle：15°
- Aligning：Non-Aligning Bearing
- Separated：Unseparated
- Rows Number：Single
- Load Direction：Radial Bearing
- Material：Bearing Steel
Base Info
- Model NO.：22211EK
- Cage：Iron,Brass,Nylon
- Inner Diameter：55mm
- Outer Diameter：100mm
- Width Diameter：25mm
- Weight：0.81kg
- Cr：129K N
- Cor：127K N
- Grease Lubrication：63001,Min
- Oil Lubrication：8500 1,Min
- Transport Package：Single Box, Plastic Barrel, Carton, Tray
- Specification：55*100*25
- Trademark：FAG
- Origin：Germen
- HS Code：8482800000
- Production Capacity：5000000,Year
Description
Limiting speeds(rpm)Mass(Kg) d D B rs min Cr Cor Grease Oil (Approx.) 222 Series 22205 25 52 18 1 36.5 36 6,500 10,000 0.186 22205K 25 52 18 1 36.5 36 6,500 10,000 0.182 22205KW33C3 25 52 18 1 36.5 36 6,500 10,000 0.182 22205W33C3 25 52 18 1 36.5 36 6,500 10,000 0.186 22206 30 62 20 1 49 49 5,700 8,800 0.287 22206K 30 62 20 1 49 49 5,700 8,800 0.282 22206KW33C3 30 62 20 1 49 49 5,700 8,800 0.282 22206W33C3 30 62 20 1 49 49 5,700 8,800 0.287 22207 35 72 23 1.1 69.5 71 4,900 7,500 0.446 22207K 35 72 23 1.1 69.5 71 4,900 7,500 0.437 22207KW33C3 35 72 23 1.1 69.5 71 4,900 7,500 0.437 22207W33C3 35 72 23 1.1 69.5 71 4,900 7,500 0.446 22208 40 80 23 1.1 79 88.5 4,300 6,600 0.526 22208K 40 80 23 1.1 79 88.5 4,300 6,600 0.515 22208KW33C3 40 80 23 1.1 79 88.5 4,300 6,600 0.515 22208W33C3 40 80 23 1.1 79 88.5 4,300 6,600 0.526 22209 45 85 23 1.1 82.5 95 3,800 5,900 0.584 22209K 45 85 23 1.1 82.5 95 3,800 5,900 0.572 22209KW33C3 45 85 23 1.1 82.5 95 3,800 5,900 0.572 22209W33C3 45 85 23 1.1 82.5 95 3,800 5,900 0.584 22210 50 90 23 1.1 86 102 3,500 5,300 0.63 22210K 50 90 23 1.1 86 102 3,500 5,300 0.616 22210KW33C3 50 90 23 1.1 86 102 3,500 5,300 0.616 22210W33C3 50 90 23 1.1 86 102 3,500 5,300 0.63 22211 55 100 25 1.5 118 144 3,200 4,900 0.808 22211K 55 100 25 1.5 118 144 3,200 4,900 0.79 22211KW33C3 55 100 25 1.5 93.5 110 3,200 4,200 0.832 22211W33C3 55 100 25 1.5 118 144 3,200 4,900 0.808 22212 60 110 28 1.5 115 147 2,900 4,500 1.15 22212K 60 110 28 1.5 115 147 2,900 4,500 1.13 22212KW33C3 60 110 28 1.5 115 147 2,900 4,500 1.13 22212W33C3 60 110 28 1.5 115 147 2,900 4,500 1.15 22213 65 120 31 1.5 143 179 2,700 4,200 1.5 22213K 65 120 31 1.5 143 179 2,700 4,200 1.47 22213KW33C3 65 120 31 1.5 143 179 2,700 4,200 1.47 22213W33C3 65 120 31 1.5 143 179 2,700 4,200 1.5
