Sk. F Spherical Roller Bearing 22224 K with 120*215*58mm
Shandong TFN Bearing Industry Co., Ltd.- Rolling Body：Roller Bearings
- The Number of Rows：Double
- Outer Dimension：Large (200-430mm)
- Material：Bearing Steel
- Spherical：Aligning Bearings
- Load Direction：Radial Bearing
Base Info
- Model NO.：22224 k
- Separated：Unseparated
- Product Name：Sk.F Spherical Roller Bearing 22224 K
- Size：120X215X58mm
- Weight：9.267kg
- Basic Dynamic Load Rating：652kn
- Basic Static Load Rating：765kn
- Fatigue Load Limit：73.5kn
- Reference Speed：2800r,Min
- Limiting Speed：3800r,Min
- Calculation Factor：0.26
- Vibration：Zv1, Zv2, Zv3, or as Requested
- Transport Package：Single Box Packaging,OEM
- Specification：120x215x58mm
- Trademark：TFN,OEM
- Origin：China
- HS Code：8482101000
- Production Capacity：10000,Month
Description
Quality Control Process 1.Assembly 2.Windage test2.Windage test 3.Cleaning 4.Rotary test 5.Greasing and gland 6.Noise inspection 7.Appearance inspection 8.Rust prevention 9.Product packaging Application low noise machine,automobile,motorcycle,and the general machinery and etc. Mass(Kg) d D B rs min Cr Cor Grease Oil (Approx.) 222 Series 22205 25 52 18 1 36.5 36 6,500 10,000 0.186 22205K 25 52 18 1 36.5 36 6,500 10,000 0.182 22205KW33C3 25 52 18 1 36.5 36 6,500 10,000 0.182 22205W33C3 25 52 18 1 36.5 36 6,500 10,000 0.186 22206 30 62 20 1 49 49 5,700 8,800 0.287 22206K 30 62 20 1 49 49 5,700 8,800 0.282 22206KW33C3 30 62 20 1 49 49 5,700 8,800 0.282 22206W33C3 30 62 20 1 49 49 5,700 8,800 0.287 22207 35 72 23 1.1 69.5 71 4,900 7,500 0.446 22207K 35 72 23 1.1 69.5 71 4,900 7,500 0.437 22207KW33C3 35 72 23 1.1 69.5 71 4,900 7,500 0.437 22207W33C3 35 72 23 1.1 69.5 71 4,900 7,500 0.446 22208 40 80 23 1.1 79 88.5 4,300 6,600 0.526 22208K 40 80 23 1.1 79 88.5 4,300 6,600 0.515 22208KW33C3 40 80 23 1.1 79 88.5 4,300 6,600 0.515 22208W33C3 40 80 23 1.1 79 88.5 4,300 6,600 0.526 22209 45 85 23 1.1 82.5 95 3,800 5,900 0.584 22209K 45 85 23 1.1 82.5 95 3,800 5,900 0.572 22209KW33C3 45 85 23 1.1 82.5 95 3,800 5,900 0.572 22209W33C3 45 85 23 1.1 82.5 95 3,800 5,900 0.584 22210 50 90 23 1.1 86 102 3,500 5,300 0.63 22210K 50 90 23 1.1 86 102 3,500 5,300 0.616 22210KW33C3 50 90 23 1.1 86 102 3,500 5,300 0.616 22210W33C3 50 90 23 1.1 86 102 3,500 5,300 0.63 22211 55 100 25 1.5 118 144 3,200 4,900 0.808 22211K 55 100 25 1.5 118 144 3,200 4,900 0.79 22211KW33C3 55 100 25 1.5 93.5 110 3,200 4,200 0.832 22211W33C3 55 100 25 1.5 118 144 3,200 4,900 0.808 22212 60 110 28 1.5 115 147 2,900 4,500 1.15 22212K 60 110 28 1.5 115 147 2,900 4,500 1.13 22212KW33C3 60 110 28 1.5 115 147 2,900 4,500 1.13 22212W33C3 60 110 28 1.5 115 147 2,900 4,500 1.15 22213 65 120 31 1.5 143 179 2,700 4,200 1.5 22213K 65 120 31 1.5 143 179 2,700 4,200 1.47 22213KW33C3 65 120 31 1.5 143 179 2,700 4,200 1.47 22213W33C3 65 120 31 1.5 143 179 2,700 4,200 1.5 22214 70 125 31 1.5 154 201 2,500 3,900 1.55 22214K 70 125 31 1.5 154 201 2,500 3,900 1.52 22214KW33C3 70 125 31 1.5 154 201 2,500 3,900 1.52 22214W33C3 70 125 31 1.5 154 201 2,500 3,900 1.55 22215 75 130 31 1.5 166 223 2,300 3,600 1.65 22215K 75 130 31 1.5 166 223 2,300 3,600 1.61 22215KW33C3 75 130 31 1.5 166 223 2,300 3,600 1.61 22215W33C3 75 130 31 1.5 166 223 2,300 3,600 1.65 22216 80 140 33 2 213 277 2,200 3,400 1.99 22216K 80 140 33 2 213 277 2,200 3,400 1.94 22216KW33C3 80 140 33 2 213 277 2,200 3,400 1.94 22216W33C3 80 140 33 2 213 277 2,200 3,400 1.99 22217 85 150 36 2 251 320 2,100 3,200 2.49 22217K 85 150 36 2 251 320 2,100 3,200 2.43 22217KW33C3 85 150 36 2 251 320 2,100 3,200 2.43 22217W33C3 85 150 36 2 251 320 2,100 3,200 2.49 22218 90 160 40 2 292 385 1,900 3,000 3.24 22218K 90 160 40 2 292 385 1,900 3,000 3.16 22218KW33C3 90 160 40 2 292 385 1,900 3,000 3.16 22218W33C3 90 160 40 2 292 385 1,900 3,000 3.24 22219 95 170 43 2.1 294 390 1,800 2,800 4.1 22219K 95 170 43 2.1 294 390 1,800 2,800 4.01 22219KW33C3 95 170 43 2.1 294 390 1,800 2,800 4.01 22219W33C3 95 170 43 2.1 294 390 1,800 2,800 4.1 22220 100 180 46 2.1 315 415 1,700 2,700 4.95 22220K 100 180 46 2.1 315 415 1,700 2,700 4.84 22220KW33C3 100 180 46 2.1 315 415 1,700 2,700 4.84 22220W33C3 100 180 46 2.1 315 415 1,700 2,700 4.95 22222 110 200 53 2.1 410 570 1,600 2,400 7.2 22222K 110 200 53 2.1 410 570 1,600 2,400 7.04 22222KW33C3 110 200 53 2.1 410 570 1,600 2,400 7.04 22222W33C3 110 200 53 2.1 410 570 1,600 2,400 7.2 22224 120 215 58 2.1 485 700 1,400 2,200 9.1 22224K 120 215 58 2.1 485 700 1,400 2,200 8.89 22224KW33C3 120 215 58 2.1 485 700 1,400 2,200 8.89 22224W33C3 120 215 58 2.1 485 700 1,400 2,200 9.1 22226 130 230 64 3 570 790 1,300 2,000 11.2 22226K 130 230 64 3 570 790 1,300 2,000 10.9 22226KW33C3 130 230 64 3 570 790 1,300 2,000 10.9 22226W33C3 130 230 64 3 570 790 1,300 2,000 11.2 22228 140 250 68 3 685 975 1,200 1,900 14 22228K 140 250 68 3 685 975 1,200 1,900 13.7 22228KW33C3 140 250 68 3 685 975 1,200 1,900 13.7 22228W33C3 140 250 68 3 685 975 1,200 1,900 14 22230 150 270 73 3 775 1160 1,100 1,700 18.1 22230K 150 270 73 3 775 1160 1,100 1,700 17.7 22230KW33C3 150 270 73 3 775 1160 1,100 1,700 17.7 22230W33C3 150 270 73 3 775 1160 1,100 1,700 18.1 22232 160 290 80 3 870 1290 1,000 1,600 22.7 22232K 160 290 80 3 870 1290 1,000 1,600 22.2 22232KW33C3 160 290 80 3 870 1290 1,000 1,600 22.2 22232W33C3 160 290 80 3 870 1290 1,000 1,600 22.7 22234 170 310 86 4 1000 1520 980 1,500 28 22234K 170 310 86 4 1000 1520 980 1,500 27.3 22234KW33C3 170 310 86 4 1000 1520 980 1,500 27.3 22234W33C3 170 310 86 4 1000 1520 980 1,500 28 22236 180 320 86 4 1040 1610 920 1,400 29.3 22236K 180 320 86 4 1040 1610 920 1,400 28.6 22236KW33C3 180 320 86 4 1040 1610 920 1,400 28.6 22236W33C3 180 320 86 4 1040 1610 920 1,400 29.3 22238 190 340 92 4 1160 1810 860 1,300 36.6 22238K 190 340 92 4 1160 1810 860 1,300 35.8 22238KW33C3 190 340 92 4 1160 1810 860 1,300 35.8 22238W33C3 190 340 92 4 1160 1810 860 1,300 36.6 22240 200 360 98 4 1310 2010 820 1,300 44 22240K 200 360 98 4 1310 2010 820 1,300 43 22240KW33C3 200 360 98 4 1310 2010 820 1,300 43 22240W33C3 200 360 98 4 1310 2010 820 1,300 44 22244 220 400 108 4 1580 2460 730 1,100 60.4 22244K 220 400 108 4 1580 2460 730 1,100 59.1 22244KW33C3 220 400 108 4 1580 2460 730 1,100 59.1 22244W33C3 220 400 108 4 1580 2460 730 1,100 60.4 22248 240 440 120 4 1940 3100 660 1,000 81.7 22248K 240 440 120 4 1940 3100 660 1,000 80 22248KW33C3 240 440 120 4 1940 3100 660 1,000 80 22248W33C3 240 440 120 4 1940 3100 660 1,000 81.7 22252 260 480 130 5 2230 3600 610 930 106 22252K 260 480 130 5 2230 3600 610 930 104 22252KW33C3 260 480 130 5 2230 3600 610 930 104 22252W33C3 260 480 130 5 2230 3600 610 930 106 22256 280 500 130 5 2310 3800 560 860 112 22256K 280 500 130 5 2310 3800 560 860 110 22256KW33C3 280 500 130 5 2310 3800 560 860 110 22256W33C3 280 500 130 5 2310 3800 560 860 112 22260 300 540 140 5 2670 4350 510 790 141 22260K 300 540 140 5 2670 4350 510 790 138 22260KW33C3 300 540 140 5 2670 4350 510 790 138 22260W33C3 300 540 140 5 2670 4350 510 790 141
spherical roller bearing packaging
FAQ of spherical roller bearing
spherical roller bearing packagingFAQ of spherical roller bearing
1.Q:Are you a factory or trading company?
A:SEMRI Bearing is specialized in manufacturing and exporting bearings.
SEMRI Bearing have own factory and warehouse.
2.Q:Can I get some samples and do you offer the sample free?
A:Yes, sure, SEMRI Bearing are honored to offer you samples.Can you buy a ticket ?3.Q:What is the payment?
A: 30% T/T In Advance, 70% T/T Against Copy Of B/L
B: 100% L/C At Sight
4.Q:What is the MOQ for bearing?
A: SEMRI Bearing MOQ is 1 pc.
5.Q:What kind of service you can offer?
A:Technology support;Installation guidance;OE
