High Precision Auto Parts Single Row Angular Contact Ball Bearing 71812AC/P4 Precision Bearing

Luoyang Bearing Research Institute Co., Ltd.
  • Contact Angle：15°
  • Aligning：Aligning Bearing
  • Separated：Unseparated
  • Rows Number：Single
  • Load Direction：Radial Bearing
  • Material：Bearing Steel

Base Info

  • Model NO.：71812AC,P4
  • Outer Diameter：90mm
  • Load Rating：P4,P2,P5
  • Inner Diameter：55mm
  • Breadth：18mm
  • Loading Rating：Cr:19.9kn Cor:12.9kn
  • Limiting Speed：Grease:19000r,Min Oil:32000r,Min
  • Weight：Abou0.41kg
  • Rolling Body：Ball Bearings
  • Number of Rows：Single
  • Outer Dimension：Small and Medium-Sized (60-115mm)
  • Accuracy Grade：P4. P4a. P2 Grade
  • Certification：ISO9001, CE, SGS, 16949
  • Other Contact Angle：15,25,40
  • OEM：Acceptable
  • Application：Machine Tool, Spindle, Motor, Separater
  • Transport Package：Standard Package for Angular Contact Ball Bearings
  • Specification：dimension for angular contact ball bearings
  • Trademark：ZYS
  • Origin：Luoyang, Henan, China
  • Production Capacity：1000000 PCS,Year

Description

Overview Product Description

 Our AdvantagesExhibitionHigh Precision Auto Parts Single Row Angular Contact Ball Bearing 71812AC/P4 Precision BearingHigh Precision Auto Parts Single Row Angular Contact Ball Bearing 71812AC/P4 Precision Bearing
