• HS Code：84678900
• Production Capacity：1000psc,Month

Basic Info.

HS Code 84678900 Production Capacity 1000psc/Month

Product Description

Characteristics:

Use with 3 jaws.
High quality, forged steel jaws and crossheads provide superior reliability and service.
Safety Cage guides jaws, holding them securely onto the part.
A built-in safety valve prevents overload.
Precise hydraulic control allows fast, efficient and safe pulling.
High force hydraulic system for effortless pulling of large components.
More efficient pulling, as one man can do the job where manual pullers ofter require two operators.
Spring-loaded live centring cone.

Model	Output (T)	Spread (mm)	Max Reach (mm)	Ram stroke (mm)	Weight (Kg)	Packing size  (cm)
HHL-5B	5	20-200	160	60	8	42*29*9
HHL-10B	10	20-300	210	80	11	43*33*11
HHL-15B	15	20-360	240	100	19	44*35*13
