- Model NO.：bu-008
- Separated：Separated
- Transport Package：Carton or According to Client′s Request
- Specification：too many specs
- Trademark：HF
- Origin：Zhejiang, China
- HS Code：8483109000
- Production Capacity：900, 000, 000PCS,Month
| Model | Sintered bronze oilite bushing |
| Material | MPIF:CT-1000-K26,SAE841, Sint A50,A51,oil-impregnated |
| Style | Sleeve, Flanged,Spherical,Miniature,Trust Washer, Rod |
| Size | 1) inner 3-70mm, also can according to your request |
| Package | inner packing: plastic bag |
| outer packing: carton, pallet |
| Physical Properties | Specific load capacity static: 10 N/mm² |
| Specific load capacity dynamic: 5 N/mm² |
| Sliding speed: 6.0 [ m/s ] |
| Friction value: 0,05 to 0,20 [ µ ] |
| Temperature strain: -40 to +200 [ °C ] |
| Max. Pv - value: 1.6 [ N/mm² x m/s ] |
| Bronze Bushing Hardness: HB 30-70 |
| Surface Roughness:0.8-1.6 |
| Yield Stength: 15,000 PSI |
| Elongation: 1% |
| " K" Strength Constent(PSI): 26,500 |
| Oil Centent: 18-22% (V) |
| Density: 6.0-6.8 g/cm³ |
| Features | Oil-impregnated; Self-lubricating |
| Wear resistant and long life service |
| High performance bearing can be in extreme load, low speed reciprocating and oscillating applications |
| Good thermal conductivity property |
| Can be used in dirty and corrosive environment |
| Noise much less than other bearing |
| Suitable for high static load |
| Can be applied in widely temperature |
| Excellent corrosion resistance |
Other Terms
| Quality Standards: ISO9001 |
| Quick Delivery: 15 Days |
| Payment Terms: T/T,L/C,Paypal |
| Shipment: By Sea / Air |
| Delivery Terms: FOB,CFR,DDU |
| Custom Registration No. : 3301970035 |
| Sliding Bearing HS-Code: 8483109000 |
