High Quality Si3n4 Ceramic Angular Contact Bearings 7007c

Zaozhuang Yiding Bearing Co., Ltd.
  • Rolling Element：Single Row
  • Structure：Angular Contact
  • Material：Ceramic
  • Load Direction：Radial Spherical Plain Bearing
  • Add Lubricant：Self-lubricating
  • Outer Structure：Whole Outer Ring

Base Info

  • Model NO.：7007C
  • Rod End：General
  • Bore Size：35 mm
  • Outside Diameter：62 mm
  • Precision Rating：P0 P2 P4 P5 P6
  • Seals Type：Open,Zz,2RS
  • Clearance：C0 C2 C3 C4 C5
  • Tolerance：Abec1 Abec3 Abec5 Abec7 Abec9
  • Vibration Velocity：V1 , V2 , V3, V4
  • Vibration Acceleration：Z1 , Z2 , Z3, V4
  • Cage：Steel,Brass,Nylon
  • Sample：Availabe
  • Transport Package：According to Per Client′s Requirements
  • Trademark：Netural
  • Origin：China
  • HS Code：8482109000
  • Production Capacity：50000 Pieces,Month

Description

Basic Info.

Model NO. 7007C Rod End General Bore Size 35 mm Outside Diameter 62 mm Precision Rating P0 P2 P4 P5 P6 Seals Type Open/Zz/2RS Clearance C0 C2 C3 C4 C5 Tolerance Abec1 Abec3 Abec5 Abec7 Abec9 Vibration Velocity V1 , V2 , V3, V4 Vibration Acceleration Z1 , Z2 , Z3, V4 Cage Steel,Brass,Nylon Sample Availabe Transport Package According to Per Client′s Requirements Trademark Netural Origin China HS Code 8482109000 Production Capacity 50000 Pieces/Month

Product Description

Si3n4 ceramic Angular Contact Bearings 7007C
Structure: Angular Contact Bearings
Type: Ball
Ceramic Ball, Ceramic Bearing
Precision Rating: ABEC-1-9, ABEC-7, P0-P6
Seals Type: Z, ZZ, RS, 2RS, OPEN
Number of Row: Single Row
Place of Origin: SHAN DONG China (Mainland)
Material: Ceramic Si3N4
Retainer: PTFE, Nylon, PEEK
Clearance codes: C0, C2, C3, C4, C5
Vibration level codes: V4, V3, V2, V1
Noise Level: Z1, Z2, Z3, Z4


7007C Si3n4 Silicon Nitride Ceramic Angular Contact Bearings can continue to operate under extremely high temperatures and are capable of operating up to 800 Deg...

7007C Si3n4 Silicon Nitride Ceramic Angular Contact Bearings are capable of withstanding heavy thrust loads and moderate radial loads. The larger the contact angle (typically in the range 10 to 45 degrees), the higher the axial load supported, but the lower the radial load. In high speed applications, such as turbines, jet engines, dentistry equipment, the centrifugal forces generated by the balls will change the contact angle at the inner and outer race.

Application:
Medical equipment,
Optical instruments,
Printing machinery,
High-speed machine tools,
High-speed motor,
Cryogenic engineering,
Food processing machinery
Packaging & Delivery
Packaging Detail: 10PCS/plastic tube or industrial packing
Delivery Detail: 3-15 days
