• Model NO.：PF205
• Bearing Block Model：PF
• Type：Bearing Housing
• Series：PF201-206
• Company Scale：38000+Sqm
• Housing Material：Cast Iron
• Brand：Fkd, Hhb, Fe, OEM
• Certificate：ISO, SGS
• Size：mm,Inch
• Seal：Black Seal, F Seal, Four Star Seal,R3 Seal
• Design：Standard Design
• Rotate Speed：2900-3500,Rpm
• Transport Package：Individual Box +Carton+Pallet
• Specification：ABEC-1
• Trademark：FKD HHB FE or OEM Brand
• Origin：Hebei Province of China
• HS Code：8483200000
• Production Capacity：One Container,Per Day

Products name
Bearing, Pillow block bearing , insert bearing

Brand name
FKD,HHB,FE or OEM Brands
ID size
Standard and non-standard sizes available
Material
Chrome Steel
Closures
Open, metal Sealed, rubber sealed, Nylon sealed
Types
For non standard bearing,there are many different types with various sizes for our clients and we can alsodesign or develop customized products as per the samples or drawings provided by our clients.
Delivery date
2-25 days
Payment terms
A: T/T
B.L/C at sight
C.D/P
About us
Hebei Hailan bearing manufacture Co., Ltd. is one of the leading bearing manufacturers in China. With 20 years' experience, advanced manufacturing facilities and excellent management staff, we can produce products that are equivalent to the world leading brand bearings. We have our own bearing brand FKD,HHB,FE  and also distribute bearings of global brands
Package
A.Polybag +Box+Carton
B.Tube+Box+Carton
C.As per customer's request


block bearing Description:
1.The pillow block bearing units are the combination of one Y-bearing(insert bearing, which is a single row deep groove ball bearing with convex sphered outside) and a plummer block housing(which has a correspondingly sphered but concave bore).

2.This bearing units are available in various materials and styles and can incorporate most of bearings. The main three types of materials for the housing include: Composite material, grey cast iron, sheet steel.

3.The plummber block units are secured on the shaft via the bearing inner ring by: (1). Grub screws; (2). Eccentric locking collar with grub screw; (3). Adapter sleeve.

The rib at the bottom of the housing mounting section provides for a robust unit that can withstand great loads from any direction. Mounted units with cast steel housings are also available in this series, and are used for applications with severe loading and shock load conditions. Tapered-bore style units are offered individually and adapters are sold separately.
