• Model NO.：SA207 SA204 SA205 SA206 SA208 SA209 SA210
• Bearing Block Model：T
• HRC：59-64
• UC201-220 ,UC305-322：UC201-220, UC305-322
• Company Scale：38000+Sqm
• Steel Ball Grade：G10
• Housing Material：Cast Iron
• Facility：Electric Furnace
• Noise Level：Z2V2
• Coordination of Bearing & Housing：H7 & J7 & K7
• Work Temperature：-25~120
• Rotate Speed：2900-3500,Rpm
• Transport Package：Plastic Bag+Individual Box +Master Carton+Pallet
• Specification：ABEC-1(P0)
• Trademark：FKD, HHB
• Origin：China
• HS Code：8483200000
• Production Capacity：200000,Week

Basic Info.

Model NO. SA207 SA204 SA205 SA206 SA208 SA209 SA210 Bearing Block Model T HRC 59-64 UC201-220 ,UC305-322 UC201-220, UC305-322 Company Scale 38000+Sqm Steel Ball Grade G10 Housing Material Cast Iron Facility Electric Furnace Noise Level Z2V2 Coordination of Bearing & Housing H7 & J7 & K7 Work Temperature -25~120 Rotate Speed 2900-3500/Rpm Transport Package Plastic Bag+Individual Box +Master Carton+Pallet Specification ABEC-1(P0) Trademark FKD, HHB Origin China HS Code 8483200000 Production Capacity 200000/Week

Product Description

Company profile:

Hebei Hailan Bearing Manufacture Co.,Ltd ( was originally founded in 1988 as Xingtai Honghai Bearing Manufacture Co.,Ltd) is one of the Chinese bearing manufacturers and exporters . It is the enterprise of well-know trademark of Hebei and high quality products of Hebei is located in the Hometown of Bearing in the LinXi county, HeBei Province, North of China,. We devote ourselves to research & development, production, promotion and application of Pillow block bearing and all other kinds of bearings .

There are more than 500 employees ,Including 50 Technicians And Engineers in our group. And the area of land is 100000sqm(Plant is 65000+sqm), We have Pillow Block Bearings automatic production line, automatic inspection line and Bearing Housing production line. We obedience to the operation philosophy of"differentiation kinds in product, technological modernization, manufactural professionalization, quality top grade, cost cheaper", We have an annual production and sales of over 19 million pieces of Pillow Block Bearings , Deep Groove Ball Bearings, Taper Roller Bearings and all other kinds of bearings , our products are widely used in various types of transmission equipment, mining machinery, engineering machinery, textile machinery, agricultural machinery, forestry machinery, construction machinery as so on .




Specifications
1)Locking option:Set screw,Eccetric locking collar,Concentric
2)UK pillow block Bearing
3)Black oxided and Zinc Plate
1.Features
1) Set screw,Eccentric locking collar,with adapter sleeves and with concentric locking collars(New)
2) UC/UR/SB/CSB/SA/CSA/HC(NA)/UK/SER/UD(SC)/UE
3) Black oxided and Zinc Plated are available.

2.Specification
1) Material for chrome steel and stainless steel available
2)Low noise and high speed
3)Large load capacity
4)High quality and long life
5)OEM welcome

3.Construction

1) UC200,UCX00 and UC300 Type ball bearingd are assembled into the various housings.The bearing insert
diameter surface is of cylindrical bore type and the setscrew are used to mount to the shaft.

2) SB200 type ball bearing is the smaller type of the UC200 type bearing.It can be used in combination with any light duty housing.Though it is small size,it has as high load bearing capacity as that of UC200 type bearing and long service life.

3)NA200 type ball bearing is assembled into various housing and it has an eccentric collor on the outside
of the inner ring for locking to the shaft.Like UC type bearing,it can be used in any place and maintains the
long bearing service life.

4)SA200 type ball bearing is sealed on the both sides with newly developed J and H type seals and it has an eccentric locking collar on the outside of the inner ring.It can be used for assembling use with any type of the housing for light duty.

5)UK200 and UK300 type ball bearing are assembled into the various housings with the adapter mounted .They are suitable to the long shaft or to the place where the shaft diameter precision is uneven,since it is provided with the complete dust-proof mechanism,the bearing service lift is surprisingly
long.

6)SER200 type ball bearing is prepared by providing the snap ring and lubtication groove at the outer diameter
surface of the CUC type.The positioning arrangement with the mbearing unit can be achieved easily and the construction of the housing can be aslo simplified.


4.The main products of our factory

- Cast iron pillow blocks

- Thermoplastic bearing housings

- All stainless steel mounted units.

- Accu-Grip Concentric lock Bearing Units(New!)

- Spherical plain bearings

- Agriculture Bearings(Disc Harrow Bearings)

- Rod ends

  -- Carbon steel rod ends.

  -- Chrome alloy steel rod ends

  -- High strength alloy steel rod ends.

  -- All stainless steel rod ends.

  -- All plastic rod ends.

  -- Aluminum rod ends.

  -- Ball Joint rod ends

  -- Self lubricated plain bearings(GE..C,GE..UK).





5.Company Introduction

1) Enterprise group combines industry with International trade

2) The 10th Year's Gold Supplier in Alibaba
3) Strict quality controll system with perfect facilities

4) Advanced production facilities

5) The abundant capability of R&D

6) High&New Tech enterprise,low carbon omission and environment friendly

Product list


ITEM	ITEM	ITEM	ITEM	ITEM	ITEM	ITEM
UC201	UCP201	UCF201	UCFL201	UCT201	UCFC201	UCPA201
UC201-8	UCP201-8	UCF201-8	UCFL201-8	UCT201-8	UCFC201-8	UCPA201-8
UC202	UCP202	UCF202	UCFL202	UCT202	UCFC202	UCPA202
UC202-10	UCP202-10	UCF202-10	UCFL202-10	UCT202-10	UCFC202-10	UCPA202-10
UC203	UCP203	UCF203	UCFL203	UCT203	UCFC203	UCPA203
UC204	UCP204	UCF204	UCFL204	UCT204	UCFC204	UCPA204
UC204-12	UCP204-12	UCF204-12	UCFL204-12	UCT204-12	UCFC204-12	UCPA204-12
UC205	UCP205	UCF205	UCFL205	UCT205	UCFC205	UCPA205
UC205-14	UCP205-14	UCF205-14	UCFL205-14	UCT205-14	UCFC205-14	UCPA205-14
UC205-15	UCP205-15	UCF205-15	UCFL205-15	UCT205-15	UCFC205-15	UCPA205-15
UC205-16	UCP205-16	UCF205-16	UCFL205-16	UCT205-16	UCFC205-16	UCPA205-16
UC206	UCP206	UCF206	UCFL206	UCT206	UCFC206	UCPA206
UC206-18	UCP206-18	UCF206-18	UCFL206-18	UCT206-18	UCFC206-18	UCPA206-18
UC206-19	UCP206-19	UCF206-19	UCFL206-19	UCT206-19	UCFC206-19	UCPA206-19
UC206-20	UCP206-20	UCF206-20	UCFL206-20	UCT206-20	UCFC206-20	UCPA206-20
UC207	UCP207	UCF207	UCFL207	UCT207	UCFC207	UCPA207
UC207-20	UCP207-20	UCF207-20	UCFL207-20	UCT207-20	UCFC207-20	UCPA207-20
UC207-21	UCP207-21	UCF207-21	UCFL207-21	UCT207-21	UCFC207-21	UCPA207-21
UC207-22	UCP207-22	UCF207-22	UCFL207-22	UCT207-22	UCFC207-22	UCPA207-22
UC207-23	UCP207-23	UCF207-23	UCFL207-23	UCT207-23	UCFC207-23	UCPA207-23
UC208	UCP208	UCF208	UCFL208	UCT208	UCFC208	UCPA208
UC208-24	UCP208-24	UCF208-24	UCFL208-24	UCT208-24	UCFC208-24	UCPA208-24
UC209	UCP209	UCF209	UCFL209	UCT209	UCFC209	UCPA209
UC209-26	UCP209-26	UCF209-26	UCFL209-26	UCT209-26	UCFC209-26	UCPA209-26
UC209-27	UCP209-27	UCF209-27	UCFL209-27	UCT209-27	UCFC209-27	UCPA209-27
UC209-28	UCP209-28	UCF209-28	UCFL209-28	UCT209-28	UCFC209-28	UCPA209-28
UC210	UCP210	UCF210	UCFL210	UCT210	UCFC210	UCPA210
UC210-30	UCP210-30	UCF210-30	UCFL210-30	UCT210-30	UCFC210-30	UCPA210-30
UC210-31	UCP210-31	UCF210-31	UCFL210-31	UCT210-31	UCFC210-31	UCPA210-31
UC210-32	UCP210-32	UCF210-32	UCFL210-32	UCT210-32	UCFC210-32	UCPA210-32
UC211	UCP211	UCF211	UCFL211	UCT211	UCFC211	UCPA211
UC211-32	UCP211-32	UCF211-32	UCFL211-32	UCT211-32	UCFC211-32	UCPA211-32
UC211-34	UCP211-34	UCF211-34	UCFL211-34	UCT211-34	UCFC211-34	UCPA211-34
UC211-35	UCP211-35	UCF211-35	UCFL211-35	UCT211-35	UCFC211-35	UCPA211-35
UC212	UCP212	UCF212	UCFL212	UCT212	UCFC212	UCPA212
UC212-36	UCP212-36	UCF212-36	UCFL212-36	UCT212-36	UCFC212-36	UCPA212-36
UC212-38	UCP212-38	UCF212-38	UCFL212-38	UCT212-38	UCFC212-38	UCPA212-38
UC212-39	UCP212-39	UCF212-39	UCFL212-39	UCT212-39	UCFC212-39	UCPA212-39
UC213	UCP213	UCF213	UCFL213	UCT213	UCFC213
UC213-40	UCP213-40	UCF213-40	UCFL213-40	UCT213-40	UCFC213-40
UC214	UCP214	UCF214	UCFL214	UCT214	UCFC214
UC214-44	UCP214-44	UCF214-44	UCFL214-44	UCT214-44	UCFC214-44
UC215	UCP215	UCF215	UCFL215	UCT215	UCFC215
UC215-47	UCP215-47	UCF215-47	UCFL215-47	UCT215-47	UCFC215-47
UC215-48	UCP215-48	UCF215-48	UCFL215-48	UCT215-48	UCFC215-48
UC216	UCP216	UCF216	UCFL216	UCT216	UCFC216
UC217	UCP217	UCF217	UCFL217	UCT217	UCFC217
UC218	UCP218	UCF218	UCFL218	UCT218	UCFC218
UC218-56	UCP218-56	UCF218-56	UCFL218-56	UCT218-56	UCFC218-56
UC305	UCP305	SA201	SB201	UK205
UC306	UCP306	SA202	SB202	UK206
UC307	UCP307	SA203	SB203	UK207
UC308	UCP308	SA204	SB204	UK208
UC309	UCP309	SA205	SB205	UK209
UC310	UCP310	SA206	SB206	UK210
UC311	UCP311	SA207	SB207	UK211
UC312	UCP312	SA208	SB208	UK212
UC313	UCP313	SA209	SB209	UK213
UC314	UCP314	SA210	SB210	UK215
UC315	UCP315			UK216
UC316	UCP316			UK217
UC317				UK218
UC318
UC319
UC320
