• Model NO.：cam follower bearing
• Separated：Unseparated
• Bearing Type：Stand Type Cam Bearing
• Bearing Name：Tjgh
• Bearing Row No.：Single Row
• Precision Rating：High Precision
• Bearing Material：Bearing Steel,Chriome Steel, Stainless Steel
• Bearing Seal Type：Sealed or Unsealed
• Bearing Cage：Steel Cage
• Lubrication：Oil or Grease
• Hardness：HRC60-65
• Bearing Application：Elevatorm, Conveyor System, Lifting etc.
• Transport Package：Standard Export Package
• Specification：SGS
• Trademark：TJGH
• Origin：China
• HS Code：84829100
• Production Capacity：1000000 PCS,Month

Bearing NumberDimensions(mm)Load ratings(kgf)DynamicStaticdDSBB1Ld1d2ιι 1rCrC0KR10310M  3x0.507817--5-0.313072KR12412M  4x0.708920--6-0.5190120KR13513M  5x0.80910233.1-7.5-0.5280180KR16616M  6x1.001112284-9-0.5330240KR19819M  8x1.251112324-11-0.5390300KR221022M10x1.251213364-13-1430370KR261026M10x1.251213364-13-1430370KR301230M12x1.50141540631461.5710620KR321232M12x1.50141540631461.5710620KR351635M16x1.501819.552631881.510401090KR401840M18x1.502021.5586320101.514101690KR472052M20x1.502425.5668422121.519402350KR522047M20x1.502425.5668422121.519402350KR622462M24x1.502930.5808425121.526003050KR722472M24x1.502930.5808425121.526003050KR803080M30x1.503537100843215234705350KR853085M30x1.503537100843215234705350KR903090M30x1.503537100843215234705350

Materials of cam follower bearings
Needle roller: Gcr15, quench-hardening HRC60-65
Rings:Gcr15
Cage:Low-carbon steel or reinforced nylon
Both the stud and yoke cam followers have an outer diameter that may either be cylindrical or crowned. The crowned. The crowned ones are often used in turntable type applications because they help reduce skidding.

Feature

- Smaller cross-section leading to greated rigidity,higher load-carrying capacity & lower inertia of the needle roller bearings help size and weight reductions in machinery.

- Though they are less wide,their load carrying capacity is high and is most suitable for applications where the load is high & the radial space is less.

- Needle roller bearings,which are designed to withstand oscillation can operate under severe conditions & interchange with sliding bearings.



Application:
(1) agricultural machinery, tractors, planter, harvesting machinery and so on.
(2) the heavy mining machinery, metallurgical machinery, mining machinery, lifting machinery, loading and unloading machinery, industrial and mining vehicles, cement equipment, etc.
(3) engineering machinery forklift, shoveling transport machinery, compaction machinery, concrete machinery, etc.
(4) petrochemical general machinery, petroleum machinery, oil machinery, chemical machinery, pump, blower, valves, gas compressor, refrigeration and air conditioning machinery, paper machinery, printing machinery, plastic processing machinery, pharmaceutical machinery, etc.
(5) the electrical machinery, power machinery, transformers, motors, high and low pressure switch, wire and cable, battery, electric welding machine, household appliances, etc.
(6) machine tools, metal cutting machine tools, forging machinery, casting machinery, woodworking machinery, etc.
(7) car, truck, road buses, cars, modified cars, motorcycles, etc.
(8) instruments: automation instrument, electrical instrumentation, optical instruments, composition analyzer, automotive instrumentation, dianliao equipment, electronic equipment, cameras, etc. Based machinery
(9) bearings, hydraulic parts, seals, powder metallurgy products, standard fasteners, industrial chain, gear, mold, etc.
(10) packaging machinery, packaging machine, packing machine, conveyor, etc.
(11) environmental protection machinery, equipment, equipment for the control of air pollution prevention and control of water pollution, solid waste treatment equipment such as mill professional special bearing, gear box, reducer special bearing.



Method of extending the bearing's lifetime:
1. The installation is correct, that affects precision, life, performance. And fill the bearing with lubricant after installation.

2. Don't allow strong impact, such as hammer striking, transfer roller pressure

3. Use the accurate installation tool, avoid to use cloth kind and short fibers

4. Lubricate the bearing to avoid rust with high quality mineral oil, especially in summer

5. General inspection, such as the surrounding temperature, vibrate, noise inspection

6. Keep bearing cleaning from dirt, dust, pollutant, moisture.

7. Bearing should not be ultra cooled.

Packaging & Shipping

 Packaging:
1.industrial packaging: plastic bag+kcraft paper+carton+plywood pallets; plastic tube+carton+plywood pallets
2.commerical packaging: 1pc/plastic bag+color box+carton+plywood pallets
3.as client's requirement

Delivery:    3-45days after received the payment

Sample

Usually by EMS, DHL, UPS, TNT, Fedex.Bulk order:Usually by sea.

Delivery

Within 7 days for Sample or below 100 pcs,30-45 days for large quantity.

Warranty

Six months warranty time for the tracker unit from the delivery date leave factory,excluded the accessories.

Payment

Through T/T, PayPal.


Please inform us when the payment made, so that we are able to arrange the productions ASAP.

If you need more information about our products,please feel free to contact us.

Your inquiry related to our product & price will be replied within 24 hours.

OEM projects are highly welcomed. We have professional team here to help.

We are expecting cooperation with you !
