• Model NO.：7308
• Place of Origin：Shandong China (Mainland)
• Outer Diameter：15 - 1820 mm
• Bore Size：5 - 820 mm
• OEM：Acceptable
• Sample：Availabe
• Transport Package：According to Per Client′s Requirements
• Trademark：Yiding
• Origin：China
• HS Code：69091100
• Production Capacity：200000 Set,Sets Per Month

Basic Info.

Model NO. 7308 Place of Origin Shandong China (Mainland) Outer Diameter 15 - 1820 mm Bore Size 5 - 820 mm OEM Acceptable Sample Availabe Transport Package According to Per Client′s Requirements Trademark Yiding Origin China HS Code 69091100 Production Capacity 200000 Set/Sets Per Month

Product Description

Bearing 7308 BE 2CA bearing ceramic bearing
Quick Details

Type:	Ceramic Ball	Brand Name:	YD or as your requirements	Bore Size:	0 - 17 mm
Outside Diameter:	0 - 26 mm	Model Number:	7308 be 2cs bearing ceramic	Place of Origin:	Shanghai, China (Mainland)
Product name:	China factory 7308 be 2cs bearing ceramic bearing	Seals Type:	Open 2RS ZZ	Application:	Medical Devices
Lubrication:	Grease	Retainer:	PTFE	Structure:	General
Cage material:	Stronger Nylon	Cage:	Iron Cage	Ball Material:	Si3N4 7308 be 2cs bearing ceramic
Material of rings:	Si3n4 7308 be 2cs bearing ceramic

Application:
They can be used as high-speed bearings, high temperature bearings, corrosion-resistant bearings, shielded bearings, electrical insulation bearings and so on.
1, Material: ZrO2, Si3N4, SiC and Al2O3, etc.
Characteristics of silicon nitride ceramic bearing:
Because of its high compressive strength, contact fatigue resistance that is superior to chrome steels, electrical resistivity and low coefficient of friction versus bearing steels, silicon nitride ceramic bearings can be widely used in aviation, aerospace, marine, petroleum, chemical, automotive, electronics, metallurgy, electric power, textile, pumps, medical equipment, scientific research, national defense, military and other domains.
Materail of bearing:
Rings: Silicon nitride ceramic
Balls: Silicon nitride balls.
Cage: PTFE, nylon 66, PEEK, SS304, etc.


Model Number	d	D	B	C	C0	Pu	reference speed	limiting speed	mass
	mm	mm	mm	kn	kn	kn	r/min	r/min	kg
7308 BECAP	40	90	23	50	32,5	1,37	10000	10000	0,61
7308 BECBJ	40	90	23	49,4	33,5	1,4	9000	9000	0,66
7308 BECBM	40	90	23	50	32,5	1,37	10000	10000	0,68
7308 BECBP	40	90	23	50	32,5	1,37	10000	10000	0,61
7308 BECBPH	40	90	23	50	32,5	1,37	10000	10000	0,61
7308 BECBY	40	90	23	49,4	33,5	1,4	9000	9000	0,64
7308 BECCY	40	90	23	49,4	33,5	1,4	9000	9000	0,64
7308 BEGAF	40	90	23	49,4	33,5	1,4	9000	9000	0,68
7308 BEGAM	40	90	23	50	32,5	1,37	10000	10000	0,68
7308 BEGAP	40	90	23	50	32,5	1,37	10000	10000	0,61
7308 BEGBM	40	90	23	50	32,5	1,37	10000	10000	0,68
7308 BEGBP	40	90	23	50	32,5	1,37	10000	10000	0,61
7308 BEGBY	40	90	23	49,4	33,5	1,4	9000	9000	0,64
7308 BEP	40	90	23	46,2	30,5	1,13	9000	9000	0,61
7308 BEY	40	90	23	49,4	33,5	1,4	9000	9000	0,64
7408 BCBM	40	110	27	70,2	45	1,9	8000	8000	1,40
7408 BGBM	40	110	27	70,2	45	1,9	8000	8000	1,40
7408 BM	40	110	27	70,2	45	1,9	8000	8000	1,40
7209 BECBJ	45	85	19	37,7	28	1,2	9000	9000	0,43
7209 BECBM	45	85	19	38	28,5	1,22	10000	10000	0,44
7209 BECBP	45	85	19	38	28,5	1,22	10000	10000	0,42
7209 BECBY	45	85	19	37,7	28	1,2	9000	9000	0,43
7209 BEGAP	45	85	19	38	28,5	1,22	10000	10000	0,42
7209 BEGAY	45	85	19	37,7	28	1,2	9000	9000	0,43
7209 BEGBY	45	85	19	37,7	28	1,2	9000	9000	0,43
7209 BEP	45	85	19	35,8	26	1,12	9000	9000	0,42
7209 BEY	45	85	19	37,7	28	1,2	9000	9000	0,43
7309 BECAP	45	100	25	61	40,5	1,73	9000	9000	0,82
7309 BECBJ	45	100	25	60,5	41,5	1,73	8000	8000	0,86
7309 BECBM	45	100	25	61	40,5	1,73	9000	9000	0,90
7309 BECBP	45	100	25	61	40,5	1,73	9000	9000	0,82
7309 BECBPH	45	100	25	61	40,5	1,73	9000	9000	0,82
7309 BECBY	45	100	25	60,5	41,5	1,73	8000	8000	0,86
7309 BEGAP	45	100	25	61	40,5	1,73	9000	9000	0,82
7309 BEGBP	45	100	25	61	40,5	1,73	9000	9000	0,82
7309 BEGBY	45	100	25	60,5	41,5	1,73	8000	8000	0,86
7309 BEP	45	100	25	55,9	37,5	1,6	8000	8000	0,82
7309 BEY	45	100	25	60,5	41,5	1,73	8000	8000	0,86

Zaozhuang Yiding Bearing Co., Ltd. is specialized in bearings export production selling and after-service. In practice for many years, we established strict quality assurance system. Our products covers Roller Bearing, Ball Bearing, Linear bearing, Rod end bearing, Joint bearing, Stainless Steel Bearings, Ceramic bearings, Plastic bearing, Thin wall bearing, Excavator bearing, and Rotor bearing. We do brands OEM service.

Any need,please kindly let us know
