Fb090 Fb092 Bronze Bearing Custom Made Bearing Bush Bronze Bushing

ANHUI QIHAN IMPORT & EXPORT CO., LTD.
  • Bearing Structure：Solid Bearing
  • Type of Lubricant：Solid-Lubricated Bearing
  • Bushing Material：Bronze
  • Bearing Direction：Thrust
  • Lubricating Way：Maintenance-Free Bearing
  • Transport Package：Carton,Box

Base Info

  • Model NO.：CHB
  • Specification：Custom-Make
  • Trademark：CHB
  • Origin：China
  • HS Code：8483300090
  • Production Capacity：10000PCS,Month

Description

Basic Info.

Model NO. CHB Specification Custom-Make Trademark CHB Origin China HS Code 8483300090 Production Capacity 10000PCS/Month

Product Description

CHB-090 bearings are wrapped from a cold formed homogeneous bronze(CuSn8 or CuSn6.5),which can achieve exceptional material properties.
The standard sizes are fitted with diamond shaped lubrication indents on the bearing surface.
These indents serve as lubricant reservoirs to rapidly build up a lubrication film at the start of movement and thereafter reduce the running friction.
The material is suitable for construction and agricultural machinery.
