• Model NO.：SER204
• Separated：Separated
• Company Scale：38000+Sqm
• Size：mm,Inch
• Series：UCP, Ucf, UCFL, Ucfc, Ucph, Ucpa etc
• Bearing Series：UC, UK, Uel, SA, Sb etc
• Bearing Housings Series：P. F. FL. pH. PA. Fb. Fa. T. FC etc
• Hardness of Bearing：HRC60-63
• Coordination of Bearing & Housing：H7 & J7 & K7
• Rotate Speed：2900-3500,Rpm
• Aplication：Motorcycle, Motor, Pump, Fan, Air Conditioner, Mic
• Export Markets：North America, South America, Eastern Europe, Sout
• Transport Package：Plastic Bag+Individual Box +Master Carton+Pallet
• Specification：ABEC-1(p0)
• Trademark：FKD FE HHB OEM
• Origin：Hebei China
• HS Code：8483200000
• Production Capacity：20000,Days

Basic Info.

Model NO. SER204 Separated Separated Company Scale 38000+Sqm Size mm/Inch Series UCP, Ucf, UCFL, Ucfc, Ucph, Ucpa etc Bearing Series UC, UK, Uel, SA, Sb etc Bearing Housings Series P. F. FL. pH. PA. Fb. Fa. T. FC etc Hardness of Bearing HRC60-63 Coordination of Bearing & Housing H7 & J7 & K7 Rotate Speed 2900-3500/Rpm Aplication Motorcycle, Motor, Pump, Fan, Air Conditioner, Mic Export Markets North America, South America, Eastern Europe, Sout Transport Package Plastic Bag+Individual Box +Master Carton+Pallet Specification ABEC-1(p0) Trademark FKD FE HHB OEM Origin Hebei China HS Code 8483200000 Production Capacity 20000/Days

Product Description

Insert bearing SER SA SB, Please contact for details.

Dimension tolerance: GB/T 3882-1995 /JIS B1558 /ISO 9628-1992.
Structure: Insert bearing with setscrew, eccentrical collar, adapte sleeve, pillow block, flange housing, pressed steel housing
Ball Bearings Inserts: GCr15 steel (JIS G4805, 100Cr6) High carbon chromium bearing steel.
Cage and the Rivet: JIS G3141 Cold rolled carbon steel sheet and strip, The material of the rivet is JIS G3507 Low carbon steel wire rods.
Housings: HT200 (JIS G5501)Gray iron casting.




Product: Insert bearings, pillow block, flange unit, housing, bearings.

Bearing No. Ref.
SER201, SER202, SER203, SER204, SER205, SER206, SER207, SER208, SER209, SER210, SER211, SER212

SA201 SA201-8 SA202 SA202-10 SA203 SA203-11 SA204-12 SA204 SA205-14 SA205-15 SA205 SA205-16 SA206-18 SA206 206-19 Bearing No. Spherical SA206-20 SA207-20 SA207-21 SA207-22 SA207 SA207-23 SA208-24 SA208-25 SA208 SA209-26 SA209-27 SA209-28 SA209 SA210-30 SA210-31 SA210 SA211-32 SA211-34 SA211 SA211-35 SA212-36 SA212 SA212-38 SA212-39

Spherical SB201 SB201-8 SB202 SB202-10 SB203 SB203-11 SB204-12 SB204 SB205-14 SB205-15 SB205 SB205-16 SB206-18 SB206 SB206-19 SB206-20 SB207-20 SB207-21 SB207-22 SB207 SB207-23 SB208-24 SB208-25 SB208 SB209-26 SB209-27 SB209-28 SB209 SB210-30 SB210-31 SB210 SB211-32 SB211-34 SB211 SB211-35 SB212-36 SB212 SB212-39

Model	Pillow block bearing
Seals Type	Black seal with star or without
Material	Chrome steel, carbon steel,Gcr15, mixed
Cage material	Steel
House weight	As you requirement
Greese	As you requirement
Guarantee	One year.
Application	Automotive components, pumps, machinery.
Certifications	ISO 9001:2008
Package	Single box  or as required.
Service	OEM service and customized service
Payment Term	T/T or L/C or Western Union
Port	Qingdao
