Nn Nj Nu Series Cylindrical Roller Bearing Nj320ecm/C4va301
Zaozhuang Yiding Bearing Co., Ltd.- Rolling Body：Roller Bearings
- The Number of Rows：Single
- Outer Dimension：Small and Medium-Sized (60-115mm)
- Material：Bearing Steel
- Spherical：Non-Aligning Bearings
- Load Direction：Radial Bearing
Base Info
- Model NO.：NJ320ECM,C4VA301
- Separated：Unseparated
- Sample：Availabe
- OEM：Acceptable
- Cage：Brass.Nylon
- Transport Package：as Per Client′s Requirement
- Origin：China
- HS Code：8482500090
- Production Capacity：60000 Pieces,Month
Description
DimensionsDynamic Static Speed rate Limit S/R Designations d(mm) D(mm) B(mm) C(kn) C0(kn) r/min 85 180 60 484 620 1400 1800 NJG 2317 VH 90 125 22 105 176 2400 3000 NCF 2918 CV 90 140 37 198 280 2200 2800 NCF 3018 CV 90 190 64 528 670 1400 1800 NJG 2318 VH 95 130 22 114 183 2200 2800 NCF 2919 CV 100 140 24 128 200 2200 2600 NCF 2920 CV 100 150 37 209 310 2000 2600 NCF 3020 CV 100 215 73 704 900 1200 1500 NJG 2320 VH 110 150 24 134 220 1900 2400 NCF 2922 CV 110 170 45 275 400 1800 2200 NCF 3022 CV 110 240 80 858 1060 1100 1300 NJG 2322 VH 120 165 27 172 290 1800 2200 NCF 2924 CV 120 180 46 292 440 1700 2000 NCF 3024 CV 120 215 58 512 735 1400 1700 NCF 2224 V 120 260 86 952 1250 1000 1200 NJG 2324 VH 130 180 30 205 360 1600 2000 NCF 2926 CV 130 200 52 413 620 1500 1900 NCF 3026 CV 130 280 93 1080 1430 950 1200 NJG 2326 VH 140 190 30 220 390 1500 1900 NCF 2928 CV 140 210 53 440 680 1400 1800 NCF 3028 CV 140 250 68 693 1020 1200 1500 NCF 2228 V 140 300 102 1210 1600 850 1100 NJG 2328 VH 150 210 36 292 490 1400 1700 NCF 2930 CV 150 225 56 457 710 1300 1600 NCF 3030 CV 150 270 73 792 1180 1100 1400 NCF 2230 V 150 320 108 1450 1930 800 1000 NJG 2330 VH 160 220 36 303 530 1300 1600 NCF 2932 CV 160 240 60 512 800 1200 1500 NCF 3032 CV 160 290 80 990 1500 950 1200 NCF 2232 V 170 230 36 314 560 1200 1500 NCF 2934 CV Principal dimension(mm) Bearing number Basic Load Rating(KN) Speed(rpm) d D B Dynamic Cr Static Cor reference Limited
Boundary Dimenssion (mm)Mass (KG) Bearing Numbers Basic Load Ratings(KN) Limited Speed(rpm) d D B r1min rsmin approx Type Cr Cor Grease Oil 15 35 11 0.6 0.3 0.05 N202 12.7 10.4 20000 22000 35 11 0.6 0.3 0.05 NJ202 12.7 10.4 20000 22000 35 11 0.6 0.3 0.05 NU202 12.7 10.4 20000 22000 17 40 12 0.6 0.3 0.06 N203 17.6 14.6 10000 18000 40 12 0.6 0.3 0.06 NJ203 14.5 12.8 18000 18000 20 47 14 1.0 0.6 0.109 N204 16.6 13.9 17000 20000 47 14 1.0 0.6 0.111 NJ204 16.6 13.9 17000 20000 47 14 1.0 0.6 0.111 NU204 16.6 13.9 17000 20000 52 15 1.1 0.6 0.149 N304 23.1 19.2 14000 17000 52 15 1.1 0.6 0.153 NJ304 23.1 19.2 14000 17000 52 15 1.1 0.6 0.153 NU304 23.1 19.2 14000 17000 25 52 15 1.0 0.6 0.134 N205 18.8 17 14000 16000 52 15 1.0 0.6 0.137 NJ205 18.8 17 14000 17000 52 18 1.1 0.6 0.17 NJ2205V 35.3 29.4 12000 25000 52 15 1.0 0.6 0.137 NU205 18.8 17 14000 16000 62 17 1.1 1.1 0.235 N305 31.5 27.7 12000 14000 62 17 1.1 1.1 0.241 NJ305 31.5 27.7 12000 14000 62 17 1.1 1.1 0.241 NU305 31.5 27.7 12000 14000 62 24 1.1 1.1 0.37 NJ2305V 67 72.7 7200 10000 30 62 16 1.0 0.6 0.203 N206 24.9 23.3 12000 14000 62 16 1.0 0.6 0.207 NJ206 24.9 23.3 12000 14000 62 16 1.0 0.6 0.207 NU206 24.9 23.3 12000 14000 72 19 1.1 1.1 0.35 N306 38.5 35 10000 12000 72 19 1.1 1.1 0.358 NJ306 38.5 35 10000 12000 72 19 1.1 1.1 0.358 NU306 38.5 35 10000 12000 35 72 17 1.1 0.6 0.289 N207 35.5 34 11000 12000 72 17 1.1 0.6 0.295 NJ207 35.5 34 11000 12000 72 17 1.1 0.6 0.295 NU207 35.5 34 11000 12000 80 21 1.5 1.1 0.451 N307 49.5 47 9000 11000 80 21 1.5 1.1 0.461 NJ307 49.5 47 9000 11000 80 21 1.5 1.1 0.461 NU307 49.5 47 9000 11000 80 21 1.5 1.5 0.536 NUP307V 77.2 78.6 10000 23000 40 80 18 1.1 1.1 0.37 N208 43.5 43 9400 11000 80 18 1.1 1.1 0.387 NJ208 43.5 43 9400 11000 80 18 1.1 1.1 0.378 NU208 43.5 43 9400 11000
Boundary Dimenssion (mm)
