51100 Series Single Direction Thrust Ball Bearing (51326)
Luoyang Huayang Special Heavy-Duty and Large Bearing Manufacturing Co., Ltd.- Contact Angle：45°
- Aligning：Non-Aligning Bearing
- Separated：Separated
- Rows Number：Single
- Load Direction：Thrust Bearing
- Material：Bearing Steel
Base Info
- Model NO.：51326
- Warranty Period：1 Year
- Precision：P0, P6, P5, P4
- Certificate：ISO9001:2008
- Outer Diameter：220mm
- Bore Diameter：130mm
- Height：75mm
- Weight：13.3kg
- Delivery Time：in Stocks, or 30 Days
- Production Experience：Since Year 1993
- Custom Design：Available
- Transport Package：Wooden Box
- Specification：ISO9001: 2008
- Trademark：LYHY
- Origin：China
- HS Code：8482104000
- Production Capacity：800PCS,Month
Description
ModelBoundary Dimension Rated Load Weight d D H C C0 New Old mm Kn kgs 51320M 8320 100 170 55 263 513 5.46 51420 8420 100 210 85 399 917 14.9 51122 8122 110 145 25 87.2 276 1.08 51222 8222 110 160 38 139 393 2.6 51322 8322 110 190 63 280 684 7.9 51422 8422 110 230 95 415 1150 20 51124 8124 120 155 25 87.1 295 1.16 51224 8224 120 170 39 136 399 2.9 51324 8324 120 210 70 330 869 9.75 51126 8126 130 170 30 109 371 1.87 51226 8226 130 190 45 186 535 4.2 51326 8326 130 225 75 358 1007 13.3 51426 8426 130 270 110 490 1520 32 51128 8128 140 180 31 111 380 2.1 51228 8228 140 200 46 191 542 4.5 51328 8328 140 240 80 396 1159 15.9 51428 8428 140 280 112 553 1750 32.2 51130 8130 150 190 31 112 380 2.2 51230 8230 150 215 51 244 698 5.8 51330 8330 150 250 80 407 1226 16.7 51132 8132 160 200 31 112 404 2.3 51232 8232 160 225 51 240 741 6.7 51332 8332 160 270 87 463 1425 21.5 51134 8134 170 215 34 137 475 3.3 51234 8234 170 240 55 280 884 8.3 51334 8334 170 280 87 445 1520 22.5 51136 8136 180 225 34 135 504 3.5 51236 8236 180 250 56 294 950 8.08 51336 8336 180 300 95 494 1738 28.7 51144 X 220 270 37 179 740 4.6 51152 8152 260 320 45 218 994 7.96 51252 8252 260 360 79 450 1900 24.8 51256 X 280 380 80 493 1950 27 51160 8160 300 380 62 322 1634 17.3 51260 8260 300 420 95 575 2613 42.5 51164 8164 320 400 63 352 1756 18.76 51264 8264 320 440 95 543 2565 43 51168 8168 340 420 64 358 1768 19.8 51268 8268 340 460 96 575 2755 45 51368 8368 340 540 160 1020 5100 142 51172X2 7708172 360 440 36 371 1805 11.3 51172 8172 360 440 65 371 1890 21.1 51272 8272 360 500 110 704 3610 69.2 X 708773Y 365 475 95 X X 40.1 X 8974H 370 529 131 X X 105 80980/YB2 9008980 400 440 24 140 700 4.47 51180 8180 400 480 65 403 2014 23 51280 8280 400 540 112 730 3800 74.5 59280 9008280 400 540 85 668 3250 53.4 51184 8184 420 500 65 410 2090 24.2 51784 8784 420 550 80 463 2574 53.6 51188 8188 440 540 80 552 2730 39 59188/YB2 9008188 440 540 60 360 2112 28.2 51288 8288 440 600 130 904 4150 109 51791 8791 455 650 120 776 4851 131 51192 8192 460 560 80 527 2850 41.7 51292 8292 460 620 130 688 4504 114 51196X1 8196K 480 600 80 585 3165 53.1 51196 8196 480 580 80 530 3100 42.5 51396 8396 480 730 195 1065 6886 308 510/500 10089/500 500 540 30 101 835 6.66 511/500 81/500 500 600 80 595 3250 45.7 512/500 82/500 500 670 135 864 5443 137 593/500 90083/500 500 750 150 950 6320 228 511/530 81/530 530 640 85 618 3311 55.8 590/560 90089/560 560 610 30 128 960 9.55 591/600 90081/600 600 710 67 630 4275 50.1 511/600 X 600 710 85 689 4445 63.5 511/630 X 630 750 95 744 4680 81.7 512/630 82/630 630 850 175 1400 10000 243 517/630 87/630 630 810 100 894 5058 126 517/635/YB2 87/635K 635 787.4 88.9 730 4690 95.2 511/670X2 81/670K 670 800 95 852 4900 93.5 510/670 10089/670 670 730 45 284 2160 20.5 511/670 81/670 670 800 105 683 5778 92.21 X 9089/708 708 950 92.8 775 970 190 572/710 70082/710 710 950 109 787 980 199.4 592/710 90082/710 710 950 145 1025 1296 284 591/750V 97081/750 750 900 90 810 6210 100 591/750 90081/750 750 900 90 741 4900 111 517/780 87/780 780 930 100 800 6069 129 512/800 X 800 1060 205 1810 12570 516 517/800 X 800 920 100 825 6120 113 511/850 81/850 850 1000 120 885 6770 173 LY5004 X 880 1020 86 840 6620 114 517/980 87/980 980 1120 120 940 7880 185 X 9089/1035 1035 1300 96.8 823 1170 311 591/1060 97081/1060 1060 1250 115 940 1240 249 510/1080 10089/1180 1180 1280 80 738 7680 108 517/1720V 7089/1720 1720 1880 80 988 12243 200 517/1095/HG2 7089/1095G2 1095 1205 55 377 2708 68.5 517/2860V 8089/2860 2860 3140 210 2434 42484 1821 517/3000V 87/3000 3000 3250 140 1612 29858 1116
