Flange Slewing Bearing for Mining Equipments (VLA200844N)
Luoyang Huayang Special Heavy-Duty and Large Bearing Manufacturing Co., Ltd.- Rolling Body：Ball Bearings
- The Number of Rows：Single
- Outer Dimension：Extra Large (440mm)
- Load Direction：Axial
- Separated：Unseparated
- ID：500-1000mm
Base Info
- Model NO.：VLA200844N
- Od：800-2500mm
- Height：50-280mm
- Application：Mining Equipments
- Transport Package：Wooden Box
- Specification：ISO9001: 2008
- Trademark：LYHY
- Origin：China
- HS Code：848210900
- Production Capacity：600PCS Per Year
Description
LYHY Slewing Ring Bearing 010 Four-point contact ball slewing ring bearing - with no gear Model Material ID mm OD mm Height mm 010.40.1000 50Mn 878 1122 100
42CrMo 878 1122 100 010.40.1120 50Mn 998 1242 100
42CrMo 998 1242 100 010.45.1250 50Mn 1110 1390 110
42CrMo 1110 1390 110 010.45.1400 50Mn 1260 1540 110
42CrMo 1260 1540 110 010.45.1600 50Mn 1460 1740 110
42CrMo 1460 1740 110 010.45.1800 50Mn 1660 1940 110
42CrMo 1660 1940 110 010.60.2000 50Mn 1825 2178 144
42CrMo 1825 2178 144 010.60.2240 50Mn 2065 2418 144
42CrMo 2065 2418 144 010.60.2500 50Mn 2325 2678 144
42CrMo 2325 2678 144 010.60.2800 50Mn 2625 2978 144
42CrMo 2625 2978 144 010.75.3150 50Mn 2922 3376 174
42CrMo 2922 3376 174 010.75.3550 50Mn 3322 3776 174
42CrMo 3322 3776 174 010.75.4000 50Mn 3772 4226 174
42CrMo 3772 4226 174 010.75.4500 50Mn 4272 4726 174
42CrMo 4272 4726 174 011 Four-point contact ball slewing ring bearing - with external gear Model Material ID mm OD mm Height mm 011.40.1000 50Mn 878 1122 100
42CrMo 878 1122 100 011.40.1120 50Mn 998 1242 100
42CrMo 998 1242 100 011.45.1250 50Mn 1110 1390 110
42CrMo 1110 1390 110 011.45.1400 50Mn 1260 1540 110
42CrMo 1260 1540 110 011.45.1600 50Mn 1460 1740 110
42CrMo 1460 1740 110 011.45.1800 50Mn 1660 1940 110
42CrMo 1660 1940 110 011.60.2000 50Mn 1825 2178 144
42CrMo 1825 2178 144 011.60.2240 50Mn 2065 2418 144
42CrMo 2065 2418 144 011.60.2500 50Mn 2325 2678 144
42CrMo 2325 2678 144 011.60.2800 50Mn 2625 2978 144
42CrMo 2625 2978 144 011.75.3150 50Mn 2922 3376 174
42CrMo 2922 3376 174 011.75.3550 50Mn 3322 3776 174
42CrMo 3322 3776 174 011.75.4000 50Mn 3772 4226 174
42CrMo 3772 4226 174 011.75.4500 50Mn 4272 4726 174
42CrMo 4272 4726 174 013 Four-point contact ball slewing ring bearing - with internal gear Model Material ID mm OD mm Height mm 013.30.630 50Mn 528 732 80
42CrMo 528 732 80 013.40.1000 50Mn 878 1122 100
42CrMo 878 1122 100 013.40.1120 50Mn 998 1242 100
42CrMo 998 1242 100 013.45.1250 50Mn 1110 1390 110
42CrMo 1110 1390 110 013.45.1400 50Mn 1260 1540 110
42CrMo 1260 1540 110 013.45.1600 50Mn 1460 1740 110
42CrMo 1460 1740 110 013.45.1800 50Mn 1660 1940 110
42CrMo 1660 1940 110 013.60.2000 50Mn 1825 2178 144
42CrMo 1825 2178 144 013.60.2240 50Mn 2065 2418 144
42CrMo 2065 2418 144 013.60.2500 50Mn 2325 2678 144
42CrMo 2325 2678 144 013.60.2800 50Mn 2625 2978 144
42CrMo 2625 2978 144 013.75.3150 50Mn 2922 3376 174
42CrMo 2922 3376 174 013.75.3550 50Mn 3322 3776 174
42CrMo 3322 3776 174 013.75.4000 50Mn 3772 4226 174
42CrMo 3772 4226 174 013.75.4500 50Mn 4272 4726 174
42CrMo 4272 4726 174
