Double Row Ball Slewing Ring Bearing for Ship Crane: 024.50.2800

Luoyang Huayang Special Heavy-Duty and Large Bearing Manufacturing Co., Ltd.
  • Separated：Separated
  • Rows Number：Double
  • Load Direction：Axial
  • ID of Slewing Ring Bearing：2585mm
  • Od of Slewing Ring Bearing：3015mm
  • Height of Slewing Ring Bearing：190mm

Base Info

  • Model NO.：024.50.2800
  • Gear Form of Slewing Ring Bearing：Internal Gear
  • Rolling Body：Ball Bearings
  • The Number of Rows：Single
  • Outer Dimension：200-6500mm
  • Transport Package：Wooden Box for Slewing Ring Bearing
  • Specification：ISO9001: 2008
  • Trademark：LYHY
  • Origin：China
  • HS Code：848210900
  • Production Capacity：600PCS Slewing Ring Bearings Per Year

Description

020 Doubel row four-point contact ball slewing bearing - without gear
Model Material ID        mm OD       mm Height  mm
020.30.1000 50Mn 858 1142 124
  42CrMo 858 1142 124
020.30.1120 50Mn 978 1262 124
  42CrMo 978 1262 124
020.40.1250 50Mn 1074 1426 160
  42CrMo 1074 1426 160
020.40.1600 50Mn 1424 1776 160
  42CrMo 1424 1776 160
020.40.1800 50Mn 1624 1976 160
  42CrMo 1624 1976 160
020.50.2000 50Mn 1785 2215 190
  42CrMo 1785 2215 190
020.50.2240 50Mn 2025 2455 190
  42CrMo 2025 2455 190
020.50.2500 50Mn 2285 2715 190
  42CrMo 2285 2715 190
020.50.2800 50Mn 2585 3015 190
  42CrMo 2585 3015 190
020.60.3150 50Mn 2872 3428 226
  42CrMo 2872 3428 226
020.60.3550 50Mn 3272 3828 226
  42CrMo 3272 3828 226
020.60.4000 50Mn 3722 4278 226
  42CrMo 3722 4278 226
020.60.4500 50Mn 4222 4778 226
  42CrMo 4222 4778 226
021/2 Doubel row four-point contact ball slewing bearing - with external gear
Model Material ID        mm OD       mm Height  mm
021.30.1000 50Mn 858 1142 124
  42CrMo 858 1142 124
021.30.1120 50Mn 978 1262 124
  42CrMo 978 1262 124
021.40.1250 50Mn 1074 1426 160
  42CrMo 1074 1426 160
021.40.1400 50Mn 1224 1576 160
  42CrMo 1224 1576 160
021.40.1600 50Mn 1424 1776 160
  42CrMo 1424 1776 160
021.40.1800 50Mn 1624 1976 160
  42CrMo 1624 1976 160
021.50.2000 50Mn 1785 2215 190
  42CrMo 1785 2215 190
021.50.2240 50Mn 2025 2455 190
  42CrMo 2025 2455 190
021.50.2500 50Mn 2285 2715 190
  42CrMo 2285 2715 190
021.50.2800 50Mn 2585 3015 190
  42CrMo 2585 3015 190
021.60.3150 50Mn 2872 3428 226
  42CrMo 2872 3428 226
021.60.3550 50Mn 3272 3828 226
  42CrMo 3272 3828 226
021.60.4000 50Mn 3722 4278 226
  42CrMo 3722 4278 226
021.60.4500 50Mn 4222 4778 226
  42CrMo 4222 4778 226
023/4 Doubel row four-point contact ball slewing bearing - with internal gear
Model Material ID        mm OD       mm Height  mm
023.30.1000 50Mn 858 1142 124
  42CrMo 858 1142 124
023.30.1120 50Mn 978 1262 124
  42CrMo 978 1262 124
023.40.1250 50Mn 1074 1426 160
  42CrMo 1074 1426 160
023.40.1400 50Mn 1224 1576 160
  42CrMo 1224 1576 160
023.40.1600 50Mn 1424 1776 160
  42CrMo 1424 1776 160
023.40.1800 50Mn 1624 1976 160
  42CrMo 1624 1976 160
023.50.2000 50Mn 1785 2215 190
  42CrMo 1785 2215 190
023.50.2240 50Mn 2025 2455 190
  42CrMo 2025 2455 190
023.50.2500 50Mn 2285 2715 190
  42CrMo 2285 2715 190
023.50.2800 50Mn 2585 3015 190
  42CrMo 2585 3015 190
023.60.3150 50Mn 2872 3428 226
  42CrMo 2872 3428 226
023.60.3550 50Mn 3272 3828 226
  42CrMo 3272 3828 226
023.60.4000 50Mn 3722 4278 226
  42CrMo 3722 4278 226
023.60.4500 50Mn 4222 4778 226
  42CrMo 4222 4778 226
