Flange Miniature Ball Bearings
Jinan Alfing Machinery Co., Ltd.- Contact Angle：Non-Aligning Bearing
- Aligning：Aligning Bearing
- Separated：Unseparated
- Rows Number：Single
- Load Direction：Radial Bearing
- Material：Bearing Steel
Base Info
- Number of Row：Single Row
- Applicable Industries：Manufacturing Plant, Machinery Repair Shops
- Transport Package：Polybag-Box-Carton
- Specification：Bearing
- Origin：Shandong
- HS Code：8482102000
- Production Capacity：5000000 Pieces , Month
Description
*1000rpmR1-4zz 1.984 6.35 2.38 3.571 284 96 67 80 R133zz 2.38 4.762 1.588 2.38 144 53 80 95 R1-5zz 2.38 7.938 2.779 3.571 552 176 60 71 R144Jzzs 6.35 2.38 2.779 311 110 67 80 R144zzs 3.175 6.35 2.38 2.779 284 96 67 80 R2-5zz 7.938 2.779 3.571 558 180 60 67 R2-6zz 9.525 2.779 3.571 640 227 53 63 R2zz 9.525 3.967 3.967 631 219 56 67 R2Azz 12.7 4.366 4.366 640 227 53 63 R155zzs 0.3967 7.938 2.779 3.175 359 150 53 63 R156zzs 7.938 2.779 3.175 359 150 53 63 R166zzs 4.762 9.525 3.175 3.175 709 272 50 60 R3zz 12.7 3.967 4.978 1301 488 43 53 R3Azz 15.875 4.978 4.978 1480 621 38 45 R168zzs 9.525 3.175 3.175 373 172 48 56 R188zz 6.35 12.7 3.175 4.762 1082 442 40 50 R4zz 15.875 4.978 4.978 1480 621 38 45 R4Azz 19.05 5.558 7.142 2336 896 36 43 R1810zzs 7.938 12.7 3.967 3.967 542 276 40 48 R6zz 9.525 22.225 5.558 7.142 3332 1422 32 38 R1038zz 9.525 15.875 3.967 3.967 815 411 28 31 R1212zz 12.7 19.05 3.967 3.967 898 524 21 26
F609 2RS Bearing
F609 2RS Flanged Deep Groove Ball Bearings: Manufactured to the same principal sizes as standard bearings these have an additional flange to allow fitting into housings flush against the shoulder of the flange. They are often used on steel tracks as guides and supports benefits: cost effective replacement bearing. As a professional miniature flange ball bearing manufacturer, we have a lot of F609 2RS Bearing inventory to ensure delivery timely.
Other Related
F609 2RS Bearing
F609 2RS Flanged Deep Groove Ball Bearings: Manufactured to the same principal sizes as standard bearings these have an additional flange to allow fitting into housings flush against the shoulder of the flange. They are often used on steel tracks as guides and supports benefits: cost effective replacement bearing. As a professional miniature flange ball bearing manufacturer, we have a lot of F609 2RS Bearing inventory to ensure delivery timely.
| Attributes | Values |
| Part Number | F609 2RS Bearing |
| Bore Dia (d) | 9 mm |
| Outer Dia (D) | 24mm |
| Flange Dia (Df) | 27mm |
| Width (B) | 7mm |
| Flange Width (Wfs) | 1.5mm |
| Bearing Type | Shielded or Seal and Open are available. |
| Material | 52100 Chrome steel, stainless steel and ceramic are available. |
| Dynamic Load Rating (Cr) (Newtons) | 2853 |
| Static Load Rating (Cor) (Newtons) | 1155 |
| Max Speed (Grease) (X1000 RPM) | 32 |
| Max Speed (Oil) (X1000 RPM) | 38 |
| Ball Qty | 7 |
| Ball Dia (Dw) | 3.9690mm |
| Weight (g) (grams) | 17.40 |
| Note | ABEC Grades 1, 3, 5, 7, and 9 are available. Also, the equivalent ISO classes. |
