Double Row Slewing Ring Bearing 023.40.1600

Luoyang Huayang Special Heavy-Duty and Large Bearing Manufacturing Co., Ltd.
  • Rolling Body：Ball Bearings
  • The Number of Rows：Double
  • Outer Dimension：200-6000mm
  • Material：50mn, 42CrMo
  • Load Direction：Axial
  • Separated：Unseparated

Base Info

  • Model NO.：023.40.1600
  • ID of Double Row Slewing Ring Bearing：1000-1500mm
  • Od of Double Row Slewing Bearing：1500-2000mm
  • Height of Double Row Slewing Bearing：150-200mm
  • Gear Form：Internal Gear
  • Transport Package：Wooden Box for Slewing Ring Bearing
  • Specification：ISO2001: 9008
  • Trademark：LYHY
  • Origin：China
  • HS Code：848210900
  • Production Capacity：60000 Pieces of Slewing Ring Bearings Per Year

Description

LYHY Slewing Ring Bearing
110 Crossed roller slewing bearings-without gear
Model Material ID        mm OD      mm Height  mm
110.28.1000 50Mn 878 1122 82
  42CrMo 878 1122 82
110.28.1120 50Mn 998 1242 82
  42CrMo 998 1242 82
110.32.1250 50Mn 1110 1390 91
  42CrMo 1110 1390 91
110.32.1400 50Mn 1260 1540 91
  42CrMo 1260 1540 91
110.32.1600 50Mn 1460 1740 91
  42CrMo 1460 1740 91
110.32.1800 50Mn 1660 1940 91
  42CrMo 1660 1940 91
110.40.2000 50Mn 1825 2178 112
  42CrMo 1825 2178 112
110.40.2240 50Mn 2065 2418 112
  42CrMo 2065 2418 112
110.40.2500 50Mn 2325 2678 112
  42CrMo 2325 2678 112
110.40.2800 50Mn 2625 2978 112
  42CrMo 2625 2978 112
110.50.3150 50Mn 2922 3376 134
  42CrMo 2922 3376 134
110.50.3550 50Mn 3322 3776 134
  42CrMo 3322 3776 134
110.50.4000 50Mn 3772 4226 134
  42CrMo 3772 4226 134
110.50.4500 50Mn 4272 4726 134
  42CrMo 4272 4726 134
111/2Crossed roller slewing bearings-with external gear
Model Material ID        mm OD       mm Height  mm
111.28.1000 50Mn 878 1122 82
  42CrMo 878 1122 82
111.28.1120 50Mn 998 1242 82
  42CrMo 998 1242 82
111.32.1250 50Mn 1110 1390 91
  42CrMo 1110 1390 91
111.32.1400 50Mn 1260 1540 91
  42CrMo 1260 1540 91
111.32.1600 50Mn 1460 1740 91
  42CrMo 1460 1740 91
111.32.1800 50Mn 1660 1940 91
  42CrMo 1660 1940 91
111.40.2000 50Mn 1825 2178 112
  42CrMo 1825 2178 112
111.40.2240 50Mn 2065 2418 112
  42CrMo 2065 2418 112
111.40.2500 50Mn 2325 2678 112
  42CrMo 2325 2678 112
111.40.2800 50Mn 2625 2978 112
  42CrMo 2625 2978 112
111.50.3150 50Mn 2922 3376 134
  42CrMo 2922 3376 134
111.50.3550 50Mn 3322 3776 134
  42CrMo 3322 3776 134
111.50.4000 50Mn 3772 4226 134
  42CrMo 3772 4226 134
111.50.4500 50Mn 4272 4726 134
  42CrMo 4272 4726 134
113/4 Crossed roller slewing bearings-with internal gear
Model Material ID        mm OD       mm Height  mm
113.28.1000 50Mn 878 1122 82
  42CrMo 878 1122 82
113.28.1120 50Mn 998 1242 82
  42CrMo 998 1242 82
113.32.1250 50Mn 1110 1390 91
  42CrMo 1110 1390 91
113.32.1400 50Mn 1260 1540 91
  42CrMo 1260 1540 91
113.32.1600 50Mn 1460 1740 91
  42CrMo 1460 1740 91
113.32.1800 50Mn 1660 1940 91
  42CrMo 1660 1940 91
113.40.2000 50Mn 1825 2178 112
  42CrMo 1825 2178 112
113.40.2240 50Mn 2065 2418 112
  42CrMo 2065 2418 112
113.40.2500 50Mn 2325 2678 112
  42CrMo 2325 2678 112
113.40.2800 50Mn 2625 2978 112
  42CrMo 2625 2978 112
113.50.3150 50Mn 2922 3376 134
  42CrMo 2922 3376 134
113.50.3550 50Mn 3322 3776 134
  42CrMo 3322 3776 134
113.50.4000 50Mn 3772 4226 134
  42CrMo 3772 4226 134
113.50.4500 50Mn 4272 4726 134
  42CrMo 4272 4726 134
