53200u High Precision Bearing Single Direction Bearing Japan NSK Thrust Ball Bearing
Jingjiang E-Asia Bearing Co., Ltd.- Separated：Separated
- Rows Number：Single
- Load Direction：Thrust Bearing
- Material：Bearing Steel
- Structure：Thrust Ball
- Stock：Rich
Base Info
- Model NO.：53200U 53201U 53202U
- Sample：Available
- Vibration & Noise Rating：Z1V1, Z2V2, Z3V3
- Clearance：C0, C1, C2, C3, C4, C5
- Precision：ABEC-1, ABEC-3, ABEC-5
- Export Markets：Global
- Rolling Body：Ball Bearings
- The Number of Rows：Single
- Outer Dimension：Small and Medium-Sized (60-115mm)
- Transport Package：Plastic Bag + Color Box + Cartocarton) + Plywood
- Trademark：NSK-TIMKEN-OEM-KOYO
- Origin：China Japan Germany Sweden America
- HS Code：84821000
- Production Capacity：10000000000000PCS,Year
Description
Bearing NOBoundary dimensions(mm) Approx Wgt (lbs.) dw dg Dw du Du Su Hu 53200U 10 12 26 18 28 3.5 13 0.09 53201U 12 14 28 20 30 3.5 13 0.1 53202U 15 17 32 24 35 4 15 0.14 53203U 17 19 35 26 38 4 15 0.16 53204U 20 22 40 30 42 5 17 0.23 53205U 25 27 47 36 50 5.5 19 0.34 53206U 30 32 52 42 55 5.5 20 0.43 53207U 35 37 62 48 65 7 22 0.62 53208U 40 42 68 55 72 7 23 0.75 53209U 45 47 73 60 78 7.5 24 0.88 53210U 50 52 78 62 82 7.5 26 1.05 53211U 55 57 90 72 95 9 30 1.7 53212U 60 62 95 78 100 9 31 1.87 53213U 65 67 100 82 105 9 32 2.05 53214U 70 72 105 88 110 9 32 2.17 53305-U 25 27 52 38 55 6 22 0.5 53306-U 30 32 60 45 62 7 25 0.72 53307-U 35 37 68 52 72 7.5 28 1.07 53308-U 40 42 78 60 82 8.5 31 1.52 53309-U 45 47 85 65 90 10 33 1.87 53310-U 50 52 95 72 100 11 37 2.73 53311-U 55 57 105 80 110 11.5 42 3.73 53312-U 60 62 110 85 115 11.5 42 3.92 53313-U 65 67 115 90 120 12.5 43 4.3 53314-U 70 72 125 98 130 13 48 5.64 53315-U 75 77 135 105 140 15 52 7.21 53316-U 80 82 140 110 145 15 52 7.56 53317-U 85 88 150 115 155 17.5 58 9.79 53318-U 90 93 155 120 160 18 59 10.4 53320-U 100 103 170 135 175 18 64 13.3 53405-U 25 27 60 42 62 8 29 0.94 53406-U 30 32 70 50 75 9 33 1.46 53407-U 35 37 80 58 85 10 37 2.12 53408-U 40 42 90 65 95 12 42 3.02 53409-U 45 47 100 72 105 12.5 46 4.01 53410-U 50 52 110 80 115 14 50 5.25 53411-U 55 57 120 88 125 15.5 55 6.84 53412-U 60 62 130 95 135 16 58 9.11 53413-U 65 68 140 100 145 17.5 65 11.6 53414-U 70 73 150 110 155 19.5 69 14 53415-U 75 78 160 115 165 21 75 17.4 53416-U 80 83 170 125 175 22 78 20.3
